Printing Method | Monochrome Laser Beam Printing |
Print Speed | |
A4 | 40 pages per minute |
Letter | 42 pages per minute |
2-Sided | 33 images per minute (A4) / 35 images per minute (Letter) |
Print Resolution | 600 x 600 dpi |
Print Quality with Image Refinement Technology | 1,200 x 1,200 dpi (equivalent) |
Warm-Up Time (From Power On) | 14s |
First Print Out Time (FPOT) (Approx.) | |
A4 | 5s |
Recovery Time (From Sleep Mode) | 4s or less |
Print Language | UFR II, PCL 6, Adobe® PostScript® 3™ |
Auto Duplex Print | Yes |
Print Margins | Top/Bottom/Left/Right margin: 5 mm Top/Bottom/Left/Right margin: 10 mm (Envelope) |
Supported File Format for USB Direct Print | JPEG, TIFF, PDF |
Input Tray Capacity (Plain Paper, 80 g/m²) | |
Standard | |
Cassette | 250 sheets |
Multi-Purpose Tray | 100 sheets |
Optional | |
Paper Feeder | 550 sheets |
Maximum | 900 sheets (Standard + 1 Paper Feeder) |
Output Tray Capacity (Plain Paper, 80 g/m2) | 150 sheets |
Media Size | |
Cassette / Paper Feeder |
A4, A5, A6, B5, Legal, Letter, Executive, Statement, Foolscap, Government Letter, Government Legal, Indian Legal, |
Multi-Purpose Tray |
A4, A5, A6, B5, Legal, Letter, Executive, Statement, Foolscap, Government Letter, Government Legal, Indian Legal, Index Card, Postcard, Envelope (COM10, Monarch, DL, C5), |
2-Sided Printing |
A4, Legal, Letter, Foolscap, Indian Legal, |
Media Type | Plain Paper, Recycled Paper, Label, Postcard, Envelope |
Media Weight | |
Cassette / Paper Feeder |
60 - 120 g/m² |
Multi-Purpose Tray |
60 - 199 g/m² |
Standard Interfaces | |
Wired | USB 2.0, 10Base-T/100Base-TX/1000Base-T |
Wireless | Wi-Fi 802.11b/g/n (Infrastructure Mode, WPS, Direct Connection) |
Network Protocol | |
LPD, RAW, WSD-Print (IPv4, IPv6) | |
Network Security | |
Wired | IP/Mac Address Filtering, HTTPS, SNMPv3, IEEE802.1X, IPsec, TLS 1.3 |
Wireless | Infrastructure Mode: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA-EAP (AES), WPA2-EAP (AES) Access Point Mode: WPA2-PSK (AES) |
Mobile/Cloud Printing Solutions | Canon PRINT Business app, Canon Print Service (Android), AirPrint, Mopria, Microsoft Universal Print |
Operating System Compatibility*1 | Windows 10/11, Windows Server 2012/2012 R2/2016/2019/2022, macOS 10.13 or later, Linux, Chrome OS |
Other Features |
Department ID, Secure Print, Application Library |
Software Included | Printer Driver, Toner Status |
Device Memory | 1 GB |
Display | 12.7 cm Color Touchscreen |
Power Requirements | AC 220 - 240 V, 50/60 Hz |
Power Consumption (Approx.) | |
Operation | 480 W (max. 1,250 W) |
Standby | 6 W |
Sleep | 0.9 W |
Operating Environment | |
Temperature | 10 - 30°C |
Humidity | 20 - 80% RH (no condensation) |
Monthly Duty Cycle*2 | 80,000 pages |
Dimensions (W x D x H) (Approx.) | 438 x 373 x 312 mm |
Weight*3 (Approx.) | 9.1 kg |
Toner Cartridge*4 | |
Standard | Cartridge 070: 3,000 Prints (Bundled: 3,000 Prints) |
High | Cartridge 070H: 10,200 Prints |
Paper Feeder | Cassette Feeding Unit-AH1 (550 sheets) |
Barcode Printing | Barcode Printing Kit-E1E |
Printing Method | Monochrome Laser Beam Printing |
Print Speed | |
A4 | 40 pages per minute |
Letter | 42 pages per minute |
2-Sided | 33 images per minute (A4) / 35 images per minute (Letter) |
Print Resolution | 600 x 600 dpi |
Print Quality with Image Refinement Technology | 1,200 x 1,200 dpi (equivalent) |
Warm-Up Time (From Power On) | 14s |
First Print Out Time (FPOT) (Approx.) | |
A4 | 5s |
Recovery Time (From Sleep Mode) | 4s or less |
Print Language | UFR II, PCL 6, Adobe® PostScript® 3™ |
Auto Duplex Print | Yes |
Print Margins | Top/Bottom/Left/Right margin: 5 mm Top/Bottom/Left/Right margin: 10 mm (Envelope) |
Input Tray Capacity (Plain Paper, 80 g/m²) | |
Standard | |
Cassette | 250 sheets |
Multi-Purpose Tray | 100 sheets |
Optional | |
Paper Feeder | 550 sheets |
Maximum | 900 sheets (Standard + 1 Paper Feeder) |
Output Tray Capacity (Plain Paper, 80 g/m²) | 150 sheets |
Media Size | |
Cassette / Paper Feeder |
A4, A5, A6, B5, Legal, Letter, Executive, Statement, Foolscap, Government Letter, Government Legal, Indian Legal, |
Multi-Purpose Tray |
A4, A5, A6, B5, Legal, Letter, Executive, Statement, Foolscap, Government Letter, Government Legal, Indian Legal, Index Card, Postcard, Envelope (COM10, Monarch, DL, C5), |
2-Sided Printing |
A4, Legal, Letter, Foolscap, Indian Legal, |
Media Type | Plain Paper, Recycled Paper, Label, Postcard, Envelope |
Media Weight | |
Cassette / Paper Feeder |
60 - 120 g/m² |
Multi-Purpose Tray |
60 - 199 g/m² |
Standard Interfaces | |
Wired | USB 2.0, 10Base-T/100Base-TX/1000Base-T |
Wireless | Wi-Fi 802.11b/g/n (Infrastructure Mode, WPS, Direct Connection) |
Network Protocol | |
LPD, RAW, WSD-Print (IPv4, IPv6) | |
Network Security | |
Wired | IP/Mac Address Filtering, HTTPS, SNMPv3, IEEE802.1X, IPsec, TLS 1.3 |
Wireless | Infrastructure Mode: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA-EAP (AES), WPA2-EAP (AES) Access Point Mode: WPA2-PSK (AES) |
Mobile/Cloud Printing Solutions | Canon PRINT Business app, Canon Print Service (Android), AirPrint, Mopria, Microsoft Universal Print |
Operating System Compatibility*1 | Windows 10/11, Windows Server 2012/2012 R2/2016/2019/2022, macOS 10.13 or later, Linux, Chrome OS |
Other Features |
Department ID, Secure Print |
Software Included | Printer Driver, Toner Status |
Device Memory | 1 GB |
Display | 6.9 cm LCD |
Power Requirements | AC 220 - 240 V, 50/60 Hz |
Power Consumption (Approx.) | |
Operation | 480 W (max. 1,250 W) |
Standby | 6 W |
Sleep | 0.9 W |
Operating Environment | |
Temperature | 10 - 30°C |
Humidity | 20 - 80% RH (no condensation) |
Monthly Duty Cycle*2 | 80,000 pages |
Dimensions (W x D x H) (Approx.) | 399 x 373 x 249 mm |
Weight*3 (Approx.) | 8.7 kg |
Toner Cartridge*4 | |
Standard | Cartridge 070: 3,000 Prints (Bundled: 3,000 Prints) |
High | Cartridge 070H: 10,200 Prints |
Paper Feeder | Cassette Feeding Unit-AH1 (550 sheets) |
Printing Method | Monochrome Laser Beam Printing |
Print Speed | |
A4 | 36 Pages per minute |
Letter | 37 Pages per minute |
2-Sided | 30 Images per minute (A4) / 31 Images per minute (Letter) |
Print Resolution | 600 x 600 dpi |
Print Quality with Image Refinement Technology | 1,200 x 1,200 dpi (equivalent) |
Warm-Up Time (From Power On) | 14s |
First Print Out Time (FPOT) (Approx.) | |
A4 | 5s |
Recovery Time (From Sleep Mode) | 4s or less |
Print Language | UFR II, PCL 6 |
Auto Duplex Print | Yes |
Print Margins | Top/Bottom/Left/Right margin: 5 mm Top/Bottom/Left/Right margin: 10 mm (Envelope) |
Input Tray Capacity (Plain Paper, 80 g/m²) | |
Standard | |
Cassette | 250 sheets |
Multi-Purpose Tray | 100 sheets |
Optional | |
Paper Feeder | 550 sheets |
Maximum | 900 sheets (Standard + 1 Paper Feeder) |
Output Tray Capacity (Plain Paper, 80 g/m2) | 150 sheets |
Media Size | |
Cassette / Paper Feeder |
A4, A5, A6, B5, Legal, Letter, Executive, Statement, Foolscap, Government Letter, Government Legal, Indian Legal, |
Multi-Purpose Tray |
A4, A5, A6, B5, Legal, Letter, Executive, Statement, Foolscap, Government Letter, Government Legal, Indian Legal, Index Card, Postcard, Envelope (COM10, Monarch, DL, C5), |
2-Sided Printing |
A4, Legal, Letter, Foolscap, Indian Legal, |
Media Type | Plain Paper, Recycled Paper, Label, Postcard, Envelope |
Media Weight | |
Cassette / Paper Feeder |
60 - 120 g/m² |
Multi-Purpose Tray |
60 - 199 g/m² |
Standard Interfaces | |
Wired | USB 2.0, 10Base-T/100Base-TX/1000Base-T |
Wireless | Wi-Fi 802.11b/g/n (Infrastructure Mode, WPS, Direct Connection) |
Network Protocol | |
LPD, RAW, WSD-Print (IPv4, IPv6) | |
Network Security | |
Wired | IP/Mac Address Filtering, HTTPS, SNMPv3, IEEE802.1X, IPsec, TLS 1.3 |
Wireless | Infrastructure Mode: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA-EAP (AES), WPA2-EAP (AES) Access Point Mode: WPA2-PSK (AES) |
Mobile/Cloud Printing Solutions | Canon PRINT Business app, Canon Print Service (Android), AirPrint, Mopria, Microsoft Universal Print |
Operating System Compatibility*1 | Windows 10/11, Windows Server 2012/2012 R2/2016/2019/2022, macOS 10.13 or later, Linux, Chrome OS |
Other Features |
Department ID |
Software Included | Printer Driver, Toner Status |
Device Memory | 1 GB |
Display | 6.9 cm LCD Display |
Power Requirements | AC 220 - 240 V, 50/60 Hz |
Power Consumption (Approx.) | |
Operation | 480 W (max. 1,250 W) |
Standby | 6 W |
Sleep | 0.9 W |
Operating Environment | |
Temperature | 10 - 30°C |
Humidity | 20 - 80% RH (no condensation) |
Monthly Duty Cycle*2 | 80,000 pages |
Dimensions (W x D x H) (Approx.) | 399 x 373 x 249 mm |
Weight*3 (Approx.) | 8.7 kg |
Toner Cartridge*4 | |
Standard | Cartridge 070: 3,000 Prints (Bundled: 1,500 Prints) |
High | Cartridge 070H: 10,200 Prints |
Printing Method | Monochrome Laser Beam Printing |
Print Speed | |
A4 | 36 pages per minute |
Letter | 37 pages per minute |
2-Sided | 30 images per minute (A4) / 31 images per minute (Letter) |
Print Resolution | 600 x 600 dpi |
Print Quality with Image Refinement Technology | 1,200 x 1,200 dpi (equivalent) |
Warm-Up Time (From Power On) | 14s |
First Print Out Time (FPOT) (Approx.) | |
A4 | 5s |
Recovery Time (From Sleep Mode) | 4s or less |
Print Language | UFR II, PCL 6, Adobe® PostScript® 3™ |
Auto Duplex Print | Yes |
Print Margins | Top/Bottom/Left/Right margin: 5 mm Top/Bottom/Left/Right margin: 10 mm (Envelope) |
Supported File Format for USB Direct Print |
JPEG, TIFF, PDF |
Copy Speed | |
A4 | 36 pages per minute |
Copy Resolution | 600 x 600 dpi |
First Copy Out Time (FCOT) (Approx.) Platen Glass |
|
A4 | 6.1s |
First Copy Out Time (FCOT) (Approx.) ADF |
|
A4 | 6.1s |
Maximum Number of Copies | Up to 999 copies |
Reduce/Enlargement | 25 - 400% in 1% increments |
Copy Features | Collate, 2 on 1, 4 on 1, ID Card Copy, Passport Copy |
Scan Resolution | |
Optical | Up to 600 x 600 dpi |
Driver Enhanced | Up to 9,600 x 9,600 dpi |
Scan Type | Colour Contact Image Sensor |
Maximum Scan Size | |
Platen Glass | Up to 216 x 297 mm |
Auto Document Feeder | Up to 216 x 356 mm |
Scan Speed *1 | |
Platen Glass | 1.9s or less |
Auto Document Feeder | 1-Sided: 50 images per minute (mono), 40 images per minute (colour) 2-Sided: 100 images per minute (mono), 80 images per minute (colour) |
Colour Depth | 24-bit |
Pull Scan | Yes, USB and Network |
Push Scan (Scan To PC) with MF Scan Utility | Yes, USB and Network |
Scan To Cloud | MF Scan Utility |
Scan Driver Compatibility | TWAIN, WIA |
Send Method |
SMB, Email, FTP |
Colour Mode |
Full Colour, Greyscale, Monochrome |
Scan Resolution |
300 x 600 dpi |
File Format |
JPEG, TIFF, PDF, Compact PDF, PDF (OCR) |
Input Tray Capacity (Plain Paper, 80 g/m²) | |
Standard | |
Cassette | 250 sheets |
Manual Feed Tray | 100 sheets |
Auto Document Feeder | 50 Sheets Duplex, Single Pass |
Optional | |
Paper Feeder | 550 sheets |
Maximum | 900 sheets (Standard + 1 Paper Feeder) |
Output Tray Capacity (Plain Paper, 80 g/m²) | 150 sheets |
Media Size | |
Paper Tray |
A4, A5, A6, B5, Legal, Letter, Executive, Statement, Foolscap, Government Letter, Government Legal, Indian Legal, Index Card, Postcard, Envelope (COM10, Monarch, DL, C5), Custom (min. 76 x 127 mm to max. 216 x 356 mm) |
Auto Document Feeder |
A4, B5, A5, B6, Letter, Legal |
2-Sided Printing |
A4, Legal, Letter, Foolscap, Indian Legal, |
Media Type | Plain Paper, Recycled Paper, Label, Postcard, Envelope |
Media Weight | |
Paper Tray |
60 - 163 g/m² |
Auto Document Feeder |
50 - 105 g/m² |
Standard Interfaces | |
Wired | USB 2.0, 10Base-T/100Base-TX/1000Base-T |
Wireless | Wi-Fi 802.11b/g/n (Infrastructure Mode, WPS, Direct Connection) |
Network Protocol | |
LPD, RAW, WSD-Print (IPv4, IPv6) | |
Scan | Email, SMB, WSD-Scan (IPv4, IPv6), FTP |
TCP/IP Application Services | Bonjour (mDNS), DHCP, BOOTP, RARP, Auto IP (IPv4), DHCPv6 (IPv6) |
Management | SNMP v1/v3 (IPv4, IPv6), HTTP/HTTPS, SNTP |
Network Security | |
Wired | IP/Mac Address Filtering, HTTPS, SNMPv3, IEEE802.1X, IPsec, TLS 1.3 |
Wireless | Infrastructure Mode: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA-EAP (AES), WPA2-EAP (AES) Access Point Mode: WPA2-PSK (AES) |
Mobile/Cloud Printing Solutions | Canon PRINT Business app, Canon Print Service (Android), AirPrint, Mopria, Microsoft Universal Print |
Operating System Compatibility*3 | Windows 10/11, Windows Server 2012/2012 R2/2016/2019/2022, macOS 10.13 or later, Linux, Chrome OS |
Other Features |
Department ID, Secure Print, Skip Blank Page, Application Library |
Software Included | Printer Driver, Scanner Driver, MF Scan Utility, Toner Status |
Device Memory | 1 GB |
Display | 12.7 cm LCD Touchscreen |
Power Requirements | AC 220 - 240 V, 50/60 Hz |
Power Consumption | |
Operation | 480 W (max. 1,280 W) |
Standby | 8 W |
Sleep | 0.9 W |
Operating Environment | |
Temperature | 10 - 30°C |
Humidity | 20 - 80% RH (no condensation) |
Monthly Duty Cycle*4 | 80,000 pages |
Dimensions (W x D x H) | 420 x 460 x 375 mm |
Weight*5 | 15.6 kg |
Printing Method | Monochrome Laser Beam Printing |
Print Speed | |
A4 | 40 pages per minute |
Letter | 42 pages per minute |
2-Sided | 33 images per minute (A4) / 35 images per minute (Letter) |
Print Resolution | 600 x 600 dpi |
Print Quality with Image Refinement Technology | 1,200 x 1,200 dpi (equivalent) |
Warm-Up Time (From Power On) | 14s |
First Print Out Time (FPOT) (Approx.) | |
A4 | 5s |
Recovery Time (From Sleep Mode) | 4s or less |
Print Language | UFR II, PCL 6, Adobe® PostScript® 3™ |
Auto Duplex Print | Yes |
Print Margins | Top/Bottom/Left/Right margin: 5 mm Top/Bottom/Left/Right margin: 10 mm (Envelope) |
Supported File Format for USB Direct Print | JPEG, TIFF, PDF |
Copy Speed | |
A4 | 40 pages per minute |
Copy Resolution | 600 x 600 dpi |
First Copy Out Time (FCOT) (Approx.) Platen Glass |
|
A4 | 6.1s |
First Copy Out Time (FCOT) (Approx.) ADF |
|
A4 | 6.1s |
Maximum Number of Copies | Up to 999 copies |
Reduce/Enlargement | 25 - 400% in 1% increments |
Copy Features | Collate, 2 on 1, 4 on 1, ID Card Copy, Passport Copy |
Scan Resolution | |
Optical | Up to 600 x 600 dpi |
Driver Enhanced | Up to 9,600 x 9,600 dpi |
Scan Type | Colour Contact Image Sensor |
Maximum Scan Size | |
Platen Glass | Up to 216 x 297 mm |
Auto Document Feeder | Up to 216 x 356 mm |
Scan Speed *1 | |
Platen Glass | 1.9s or less |
Auto Document Feeder | 1-Sided: 50 images per minute (mono), 40 images per minute (colour) 2-Sided: 100 images per minute (mono), 80 images per minute (colour) |
Colour Depth | 24-bit |
Pull Scan | Yes, USB and Network |
Push Scan (Scan To PC) with MF Scan Utility | Yes, USB and Network |
Scan To Cloud | MF Scan Utility |
Scan Driver Compatibility | TWAIN, WIA |
Send Method |
SMB, Email, FTP, iFAX Simple |
Colour Mode |
Full Colour, Greyscale, Monochrome |
Scan Resolution |
300 x 600 dpi |
File Format |
JPEG, TIFF, PDF, Compact PDF, PDF (OCR) |
Modem Speed |
Up to 33.6 Kbps (Up to 3 s/page) |
Fax Resolution |
Up to 200 x 400 dpi |
Compression Method |
MH, MR, MMR, JBIG |
Memory Capacity *2 |
Up to 256 pages |
Speed Dials |
Up to 104 dials |
Group Dials / Destinations |
Max. 103 dials / Max. 50 destinations in one group |
Sequential Broadcast |
Max. 114 destinations |
Receive Mode |
Fax only, Fax/Tel Auto Switch, Answer Mode, Manual |
Memory Backup |
Permanent fax memory backup |
Fax Features |
Fax Forwarding, Remote Reception, PC Fax (Transmit only) DRPD, ECM, Auto Redial, Fax Activity Reports, Fax Activity Result Reports, Fax Activity Management Reports |
Input Tray Capacity (Plain Paper, 80 g/m²) | |
Standard | |
Cassette | 250 sheets |
Manual Feed Tray | 100 sheets |
Auto Document Feeder | 50 Sheets Duplex, Single Pass |
Optional | |
Paper Feeder | 550 sheets |
Maximum | 900 sheets (Standard + 1 Paper Feeder) |
Output Tray Capacity (Plain Paper, 80 g/m²) | 150 sheets |
Media Size | |
Paper Tray |
A4, A5, A6, B5, Legal, Letter, Executive, Statement, Foolscap, Government Letter, Government Legal, Indian Legal, Index Card, Postcard, Envelope (COM10, Monarch, DL, C5), Custom (min. 76 x 127 mm to max. 216 x 356 mm) |
Auto Document Feeder |
A4, B5, A5, B6, Letter, Legal |
2-Sided Printing |
A4, Legal, Letter, Foolscap, Indian Legal, |
Media Type | Plain Paper, Recycled Paper, Label, Postcard, Envelope |
Media Weight | |
Paper Tray |
60 - 163 g/m² |
Auto Document Feeder |
50 - 105 g/m² |
Standard Interfaces | |
Wired | USB 2.0, 10Base-T/100Base-TX/1000Base-T |
Wireless | Wi-Fi 802.11b/g/n (Infrastructure Mode, WPS, Direct Connection) |
Network Protocol | |
LPD, RAW, WSD-Print (IPv4, IPv6) | |
Scan | Email, SMB, WSD-Scan (IPv4, IPv6), FTP |
TCP/IP Application Services | Bonjour (mDNS), DHCP, BOOTP, RARP, Auto IP (IPv4), DHCPv6 (IPv6) |
Management | SNMP v1/v3 (IPv4, IPv6), HTTP/HTTPS, SNTP |
Network Security | |
Wired | IP/Mac Address Filtering, HTTPS, SNMPv3, IEEE802.1X, IPsec, TLS 1.3 |
Wireless | Infrastructure Mode: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA-EAP (AES), WPA2-EAP (AES) Access Point Mode: WPA2-PSK (AES) |
Mobile/Cloud Printing Solutions | Canon PRINT Business app, Canon Print Service (Android), AirPrint, Mopria, Microsoft Universal Print |
Operating System Compatibility*3 | Windows 10/11, Windows Server 2012/2012 R2/2016/2019/2022, macOS 10.13 or later, Linux, Chrome OS |
Other Features | Department ID, Secure Print, Skip Blank Page, Application Library |
Software Included | Printer Driver, Fax Driver, Scanner Driver, MF Scan Utility, Toner Status |
Device Memory | 1 GB |
Display | 12.7 cm LCD Touchscreen with vari-angle |
Power Requirements | AC 220 - 240 V, 50/60 Hz |
Power Consumption | |
Operation | 480 W (max. 1,280 W) |
Standby | 8 W |
Sleep | 0.9 W |
Operating Environment | |
Temperature | 10 - 30°C |
Humidity | 20 - 80% RH (no condensation) |
Monthly Duty Cycle*4 | 80,000 pages |
Dimensions (W x D x H) | 420 x 460 x 375 mm |
Weight*5 | 15.6 kg |
Toner Cartridge*6 | |
Standard | Cartridge 070: 3,000 Prints (Bundled: 3,000 Prints) |
High | Cartridge 070H: 10,200 Prints |
Printing Method | Monochrome Laser Beam Printing |
Print Speed | |
A4 | 40 pages per minute |
Letter | 42 pages per minute |
2-Sided | 33 images per minute (A4) / 35 images per minute (Letter) |
Print Resolution | 600 x 600 dpi |
Print Quality with Image Refinement Technology | 1,200 x 1,200 dpi (equivalent) |
Warm-Up Time (From Power On) | 14s |
First Print Out Time (FPOT) (Approx.) | |
A4 | 5s |
Recovery Time (From Sleep Mode) | 4s or less |
Print Language | UFR II, PCL 6, Adobe® PostScript® 3™ |
Auto Duplex Print | Yes |
Print Margins | Top/Bottom/Left/Right margin: 5 mm Top/Bottom/Left/Right margin: 10 mm (Envelope) |
Supported File Format for USB Direct Print | JPEG, TIFF, PDF |
Copy Speed | |
A4 | 40 pages per minute |
Copy Resolution | 600 x 600 dpi |
First Copy Out Time (FCOT) (Approx.) Platen Glass |
|
A4 | 6.1s |
First Copy Out Time (FCOT) (Approx.) ADF |
|
A4 | 6.1s |
Maximum Number of Copies | Up to 999 copies |
Reduce/Enlargement | 25 - 400% in 1% increments |
Copy Features | Collate, 2 on 1, 4 on 1, ID Card Copy, Passport Copy |
Scan Resolution | |
Optical | Up to 600 x 600 dpi |
Driver Enhanced | Up to 9,600 x 9,600 dpi |
Scan Type | Colour Contact Image Sensor |
Maximum Scan Size | |
Platen Glass | Up to 216 x 297 mm |
Auto Document Feeder | Up to 216 x 356 mm |
Scan Speed *1 | |
Platen Glass | 1.9s or less |
Auto Document Feeder | 1-Sided: 50 images per minute (mono), 40 images per minute (colour) 2-Sided: 100 images per minute (mono), 80 images per minute (colour) |
Colour Depth | 24-bit |
Pull Scan | Yes, USB and Network |
Push Scan (Scan To PC) with MF Scan Utility | Yes, USB and Network |
Scan To Cloud | MF Scan Utility |
Scan Driver Compatibility | TWAIN, WIA |
Send Method |
SMB, Email, FTP, iFAX Simple |
Colour Mode |
Full Colour, Greyscale, Monochrome |
Scan Resolution |
300 x 600 dpi |
File Format |
JPEG, TIFF, PDF, Compact PDF, PDF (OCR) |
Modem Speed |
Up to 33.6 Kbps (Up to 3 s/page) |
Fax Resolution |
Up to 200 x 400 dpi |
Compression Method |
MH, MR, MMR, JBIG |
Memory Capacity *2 |
Up to 256 pages |
Speed Dials |
Up to 104 dials |
Group Dials / Destinations |
Max. 103 dials / Max. 50 destinations in one group |
Sequential Broadcast |
Max. 114 destinations |
Receive Mode |
Fax only, Fax/Tel Auto Switch, Answer Mode, Manual |
Memory Backup |
Permanent fax memory backup |
Fax Features |
Fax Forwarding, Remote Reception, PC Fax (Transmit only) DRPD, ECM, Auto Redial, Fax Activity Reports, Fax Activity Result Reports, Fax Activity Management Reports |
Input Tray Capacity (Plain Paper, 80 g/m²) | |
Standard | |
Cassette | 250 sheets |
Manual Feed Tray | 100 sheets |
Auto Document Feeder | 50 Sheets Duplex, Single Pass |
Optional | |
Paper Feeder | 550 sheets |
Maximum | 900 sheets (Standard + 1 Paper Feeder) |
Output Tray Capacity (Plain Paper, 80 g/m²) | 150 sheets |
Media Size | |
Paper Tray |
A4, A5, A6, B5, Legal, Letter, Executive, Statement, Foolscap, Government Letter, Government Legal, Indian Legal, Index Card, Postcard, Envelope (COM10, Monarch, DL, C5), Custom (min. 76 x 127 mm to max. 216 x 356 mm) |
Auto Document Feeder |
A4, B5, A5, B6, Letter, Legal |
2-Sided Printing |
A4, Legal, Letter, Foolscap, Indian Legal, |
Media Type | Plain Paper, Recycled Paper, Label, Postcard, Envelope |
Media Weight | |
Paper Tray |
60 - 163 g/m² |
Auto Document Feeder |
50 - 105 g/m² |
Standard Interfaces | |
Wired | USB 2.0, 10Base-T/100Base-TX/1000Base-T |
Wireless | Wi-Fi 802.11b/g/n (Infrastructure Mode, WPS, Direct Connection) |
Network Protocol | |
LPD, RAW, WSD-Print (IPv4, IPv6) | |
Scan | Email, SMB, WSD-Scan (IPv4, IPv6), FTP |
TCP/IP Application Services | Bonjour (mDNS), DHCP, BOOTP, RARP, Auto IP (IPv4), DHCPv6 (IPv6) |
Management | SNMP v1/v3 (IPv4, IPv6), HTTP/HTTPS, SNTP |
Network Security | |
Wired | IP/Mac Address Filtering, HTTPS, SNMPv3, IEEE802.1X, IPsec, TLS 1.3 |
Wireless | Infrastructure Mode: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA-EAP (AES), WPA2-EAP (AES) Access Point Mode: WPA2-PSK (AES) |
Mobile/Cloud Printing Solutions | Canon PRINT Business app, Canon Print Service (Android), AirPrint, Mopria, Microsoft Universal Print |
Operating System Compatibility*3 | Windows 10/11, Windows Server 2012/2012 R2/2016/2019/2022, macOS 10.13 or later, Linux, Chrome OS |
Other Features | Department ID, Secure Print, Skip Blank Page, Application Library |
Software Included | Printer Driver, Fax Driver, Scanner Driver, MF Scan Utility, Toner Status |
Device Memory | 1 GB |
Display | 12.7 cm LCD Touchscreen with vari-angle |
Power Requirements | AC 220 - 240 V, 50/60 Hz |
Power Consumption | |
Operation | 480 W (max. 1,280 W) |
Standby | 8 W |
Sleep | 0.9 W |
Operating Environment | |
Temperature | 10 - 30°C |
Humidity | 20 - 80% RH (no condensation) |
Monthly Duty Cycle*4 | 80,000 pages |
Dimensions (W x D x H) | 420 x 460 x 375 mm |
Weight*5 | 15.6 kg |
Printing Method | Monochrome Laser Beam Printing |
Print Speed | |
A4 | 30 pages per minute |
Letter | 30 pages per minute |
A3 | 15 pages per minute |
Print Resolution | 600 x 600 dpi |
Print Quality with Image Refinement Technology | 1,200 x 1,200 dpi (equivalent) |
Warm-Up Time (From Power On) | 40s |
First Print Out Time (FPOT) (Approx.) | |
A4 | 6.3s |
Recovery Time (From Sleep Mode) | 5s or less |
Print Language | UFR II LT |
Print Margins | Top/Bottom/Left/Right margin: 5 mm Top/Bottom/Left/Right margin: 10 mm (Envelope) |
Input Tray Capacity (Plain Paper, 80 g/m²) |
|
Standard | |
Cassette | 250 sheets |
Multi-purpose Tray | 100 sheets |
Optional | |
Paper Feeder | 550 sheets (x3) |
Maximum | 2,000 sheets (Standard + 3 Paper Feeders) |
Output Tray Capacity (Plain Paper, 80 g/m²) |
250 sheets |
Media Size | |
Cassette / Paper Feeder |
A3, A4, A5, B5, B6, Legal, Letter, Executive, Statement, Foolscap, Custom (min. 85 x 148 mm to max. 297 x 431.8 mm) |
Multi-purpose Tray |
A3, A4, A5, B4, B5, Legal, Letter, Executive, Statement, Foolscap, Postcard, Envelope (COM10, Monarch, DL, C5), Custom (min. 76.2 x 127 mm to max. 312 to 1,200 mm) |
Media Type | Plain Paper, Recycled Paper, Label, Postcard, Envelope |
Media Weight | |
Standard Cassette / Paper Feeder |
60 - 120 g/m² |
Multi-Purpose Tray |
60 - 199 g/m² |
Standard Interfaces | |
Wired | USB 2.0 High Speed, 10Base-T/100Base-TX/1000Base-T |
Wireless | Wi-Fi 802.11b/g/n (Infrastructure Mode, WPS, Direct Connection) |
Network Protocol | |
LPD, RAW, WSD-Print (IPv4, IPv6) | |
TCP/IP Application Services | Bonjour (mDNS), HTTP, HTTPS, POP before SMTP (IPv4, IPv6), DHCP, ARP+PING, Auto IP, WINS (IPv4), DHCPv6 (IPv6) |
Management | SNMPv1, SNMPv3 (IPv4, IPv6) |
Network Security | |
Wired | IP/Mac address filtering, HTTPS, SNMPv3, IEEE802.1X, IPSEC, TLS 1.3, Dual Network Support |
Wireless | Infrastructure Mode: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA-EAP (AES), WPA2-EAP (AES), IEEE802.1X Access Point Mode: WPA2-PSK (AES) |
Other Features | Department ID, Forced Hold Printing, Secure Print |
Mobile Solution | Canon PRINT Business, Canon Print Service, Apple® AirPrint®, Mopria® Print Service, Microsoft Universal Print |
Compatible Operating Systems*1 | Windows®, Windows Server®, Mac® OS, Linux, Chrome OS |
Software Included | Printer Driver, Toner Status |
Device Memory | 2 GB |
Display | 6.9 cm LCD |
Power Requirements | AC 220 - 240 V, 50/60 Hz |
Power Consumption (Approx.) | |
Operation | 650 W (max. 1,380 W) |
Standby | 30 W |
Sleep | 1.2 W |
Operating Environment | |
Temperature | 10 - 30°C |
Humidity | 20 - 80% RH (no condensation) |
Monthly Duty Cycle*2 | 100,000 pages |
Dimensions (W x D x H) (Approx.) | 484 x 458 x 297 mm |
Weight*3 (Approx.) | 20.8 kg |
Toner Cartridge*4 | |
Standard | Cartridge 062: 11,000 Prints (Bundled: 6,400 Prints) |
Printing Method | Monochrome Laser Beam Printing |
Print Speed | |
A4 | 43 pages per minute |
Letter | 43 pages per minute |
2-Sided | 43 pages per minute (A4) or 21.5 sheets per minute |
A3 | 22 pages per minute |
Print Resolution | 600 x 600 dpi |
Print Quality with Image Refinement Technology | 1,200 x 1,200 dpi (equivalent) |
Warm-Up Time (From Power On) | 40s |
First Print Out Time (FPOT) (Approx.) | |
A4 | 6.3s |
Recovery Time (From Sleep Mode) | 5s or less |
Print Language | UFR II, PCL 6, Adobe® PostScript® 3™ |
Auto Duplex Print | Yes |
Print Margins | Top/Bottom/Left/Right margin: 5 mm Top/Bottom/Left/Right margin: 10 mm (Envelope) |
Supported File Format for USB Direct Print | JPEG, TIFF, PDF, XPS |
Input Tray Capacity (Plain Paper, 80 g/m²) |
|
Standard | |
Cassette | 250 sheets |
Multi-purpose Tray | 100 sheets |
Optional | |
Paper Feeder | 550 sheets (x3) |
Maximum | 2,000 sheets (Standard + 3 Paper Feeders) |
Output Tray Capacity (Plain Paper, 80 g/m²) |
250 sheets |
Media Size | |
Cassette / Paper Feeder |
A3, A4, A5, B4, B5, Legal, Letter, Executive, Statement, Foolscap, Custom (min. 85 x 148 mm to max. 297 x 431.8 mm) |
Multi-purpose Tray |
A3, A4, A5, B4, B5, Legal, Letter, Executive, Statement, Foolscap, Postcard, Envelope (COM10, Monarch, DL, C5), Custom (min. 76.2 x 127 mm to max. 312 to 1,200 mm) |
2-Sided Printing |
A3, A4, A5, B5, Legal, Letter, Executive, Foolscap |
Media Type | Plain Paper, Recycled Paper, Label, Postcard, Envelope |
Media Weight | |
Standard Cassette / Paper Feeder |
60 - 120 g/m² |
Multi-Purpose Tray |
60 - 199 g/m² |
2-Sided Printing |
60 - 120 g/m² |
Standard Interfaces | |
Wired | USB 2.0 High Speed, 10Base-T/100Base-TX/1000Base-T |
Wireless | Wi-Fi 802.11b/g/n (Infrastructure Mode, WPS, Direct Connection) |
Network Protocol | |
LPD, RAW, WSD-Print (IPv4, IPv6) | |
TCP/IP Application Services | Bonjour (mDNS), HTTP, HTTPS, POP before SMTP (IPv4, IPv6), DHCP, ARP+PING, Auto IP, WINS (IPv4), DHCPv6 (IPv6) |
Management | SNMPv1, SNMPv3 (IPv4, IPv6) |
Network Security | |
Wired | IP/Mac address filtering, HTTPS, SNMPv3, IEEE802.1X, IPSEC, TLS 1.3, Dual Network Support |
Wireless | Infrastructure Mode: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA-EAP (AES), WPA2-EAP (AES), IEEE802.1X Access Point Mode: WPA2-PSK (AES) |
Other Features | Department ID, Forced Hold Printing, Secure Print |
Mobile Solution | Canon PRINT Business, Canon Print Service, Apple® AirPrint®, Mopria® Print Service, Microsoft Universal Print |
Compatible Operating Systems*1 | Windows®, Windows Server®, Mac® OS, Linux, Chrome OS |
Software Included | Printer Driver, Toner Status |
Device Memory | 2 GB |
Display | 6.9 cm LCD |
Power Requirements | AC 220 - 240 V, 50/60 Hz |
Power Consumption (Approx.) | |
Operation | 700 W (max. 1,380 W) |
Standby | 30 W |
Sleep | 1.2 W |
Operating Environment | |
Temperature | 10 - 30°C |
Humidity | 20 - 80% RH (no condensation) |
Monthly Duty Cycle*2 | 100,000 pages |
Dimensions (W x D x H) (Approx.) | 484 x 565 x 297 mm |
Weight*3 (Approx.) | 25.5 kg |
Toner Cartridge*4 | |
Standard | Cartridge 062: 11,000 Prints (Bundled: 6,400 Prints ) |
Printing Method | Monochrome Laser Beam Printing |
Print Speed *1 | |
A4 | 29 pages/minute |
Letter | 30 pages/minute |
2-Sided | 18 pages/minute (A4) / 19 pages/minute (Letter) |
Print Resolution | 600 x 600 dpi |
Print Quality with Image Refinement Technology | 2,400 (equivalent) x 600 dpi |
Warm-Up Time (From Power On) | 7.5s |
First Print Out Time (FPOT) *1 (Approx.) | |
A4 | 5.4s |
Recovery Time (From Sleep Mode) | 3.2s |
Print Language | UFR II |
Auto Duplex Print | Yes |
Print Margins | Top/Bottom/Left/Right margin: 5 mm Top/Bottom/Left/Right margin: 10 mm (Envelope) |
Copy Speed *1 | |
A4 | 29 pages/minute |
Copy Resolution | 600 × 600 dpi |
First Copy Out Time (FCOT) (Approx.) Platen Glass |
|
A4 | 7.6s |
Maximum Number of Copies | Up to 999 copies |
Reduce/Enlargement | 25 - 400% in 1% increments |
Copy Features | Collate, 2 on 1, 4 on 1, ID Card Copy, Passport Copy |
Scan Resolution | |
Optical | Up to 600 x 600 dpi |
Driver Enhanced | Up to 9,600 x 9,600 dpi |
Scan Type | Colour Contact Image Sensor |
Maximum Scan Size | |
Platen Glass | Up to 216 x 297 mm |
Scan Speed *2 | |
Platen Glass | 3.5s or less |
Colour Depth | 24-bit |
Pull Scan | Yes, USB and Network |
Push Scan (Scan To PC) with MF Scan Utility | Yes, USB and Network |
Scan To Cloud | MF Scan Utility |
Scan Driver Compatibility | TWAIN, WIA |
Input Tray Capacity (Plain Paper, 80 g/m² (gsm)) |
|
Standard | |
Paper Tray | 150 sheets |
Output Tray Capacity (Plain Paper, 80 g/m² (gsm)) |
100 sheets |
Media Size | |
Paper Tray |
A4, A5, A6, B5, Legal, Letter, Executive, Statement, Foolscap, Government Letter, Government Legal, Indian Legal, Index Card, Postcard, Envelope (COM10, Monarch, DL, C5), |
2-Sided Printing |
A4, Legal, Letter, Foolscap, Indian Legal, |
Media Type | Plain Paper, Recycled Paper, Label, Postcard, Envelope |
Media Weight | |
Paper Tray |
60 - 163 g/m² (gsm) |
Standard Interfaces | |
Wired | USB 2.0 High Speed, 10Base-T/100Base-TX |
Network Protocol | |
LPD, RAW, WSD-Print (IPv4, IPv6) | |
TCP/IP Application Services | Bonjour(mDNS), DHCP, BOOTP, RARP, Auto IP (IPv4), DHCPv6 (IPv6) |
Management | SNMP v1/v3 (IPv4, IPv6), HTTP/HTTPS, SNTP |
Network Security | |
Wired | IP/Mac Address Filtering, HTTPS, SNMPv3, IEEE802.1X, TLS 1.3 |
Mobile Solution | Canon PRINT Business, Canon Print Service, Apple® AirPrint®, Mopria® Print Service, Microsoft Universal Print |
Compatible Operating Systems*3 | Windows®, Windows Server®, Mac® OS, Linux, Chrome OS |
Software Included | Printer Driver, Scanner Driver, MF Scan Utility, Toner Status |
Device Memory | 256 MB |
Display | 5.3cm (5-Line) LCD |
Power Requirements | AC 220 - 240 V, 50/60 Hz |
Power Consumption (Approx.) | |
Operation | 530 W (maximum 1,300 W) |
Standby | 5.8 W |
Sleep | 1.0 W |
Operating Environment | |
Temperature | 10 - 30°C |
Humidity | 20 - 80% RH (no condensation) |
Monthly Duty Cycle*4 | 20,000 prints |
Dimensions (W x D x H) (Approx.) | 372 x 320 x 271 mm |
Weight*5 (Approx.) | 8.6 kg |
Printing Method | Monochrome Laser Beam Printing |
Print Speed *1 | |
A4 | 29 pages/minute |
Letter | 30 pages/minute |
2-Sided | 18 pages/minute (A4) / 19 pages/minute (Letter) |
Print Resolution | 600 x 600 dpi |
Print Quality with Image Refinement Technology | 2,400 (equivalent) x 600 dpi |
Warm-Up Time (From Power On) | 7.5s |
First Print Out Time (FPOT) *1 (Approx.) | |
A4 | 5.4s |
Recovery Time (From Sleep Mode) | 3.2s |
Print Language | UFR II |
Auto Duplex Print | Yes |
Print Margins | Top/Bottom/Left/Right margin: 5 mm Top/Bottom/Left/Right margin: 10 mm (Envelope) |
Copy Speed *1 | |
A4 | 29 pages/minute |
Copy Resolution | 600 × 600 dpi |
First Copy Out Time (FCOT) (Approx.) Platen Glass |
|
A4 | 7.6s |
First Copy Out Time (FCOT) (Approx.) ADF |
|
A4 | 8.9s |
Maximum Number of Copies | Up to 999 copies |
Reduce/Enlargement | 25 - 400% in 1% increments |
Copy Features | Collate, 2 on 1, 4 on 1, ID Card Copy, Passport Copy |
Scan Resolution | |
Optical | Up to 600 x 600 dpi |
Driver Enhanced | Up to 9,600 x 9,600 dpi |
Scan Type | Colour Contact Image Sensor |
Maximum Scan Size | |
Platen Glass | Up to 216 x 297 mm |
Auto Document Feeder | Up to 216 x 356 mm |
Scan Speed *2 | |
Platen Glass | 3.5s or less |
Auto Document Feeder | 20 images/minute (mono), 15 images/minute (colour) |
Colour Depth | 24-bit |
Pull Scan | Yes, USB and Network |
Push Scan (Scan To PC) with MF Scan Utility | Yes, USB and Network |
Scan To Cloud | MF Scan Utility |
Scan Driver Compatibility | TWAIN, WIA |
Modem Speed |
Up to 33.6 Kbps (Up to 3s/page) |
Fax Resolution |
Up to 200 x 400 dpi |
Compression Method |
MH, MR, MMR, JBIG |
Memory Capacity *3 |
Up to 256 pages |
Speed Dials |
Up to 104 dials |
Group Dials / Destinations |
Maximum 103 dials / Maximum 50 destinations in one group |
Sequential Broadcast |
Maximum 114 destinations |
Receive Mode |
Fax only, Fax/Tel Auto Switch, Answer Mode, Manual |
Memory Backup |
Permanent fax memory backup |
Fax Features |
Fax Forwarding, Remote Reception, PC Fax (Transmit only) DRPD, ECM, Auto Redial, Fax Activity Reports, Fax Activity Result Reports, Fax Activity Management Reports |
Input Tray Capacity (Plain Paper, 80 g/m² (gsm)) |
|
Standard | |
Paper Tray | 150 sheets |
Auto Document Feeder | 35 sheets |
Output Tray Capacity (Plain Paper, 80 g/m² (gsm)) |
100 sheets |
Media Size | |
Paper Tray |
A4, A5, A6, B5, Legal, Letter, Executive, Statement, Foolscap, Government Letter, Government Legal, Indian Legal, Index Card, Postcard, Envelope (COM10, Monarch, DL, C5), |
Auto Document Feeder |
A4, B5, A5, B6, Letter, Legal |
2-Sided Printing |
A4, Legal, Letter, Foolscap, Indian Legal, |
Media Type | Plain Paper, Recycled Paper, Label, Postcard, Envelope |
Media Weight | |
Paper Tray |
60 - 163 g/m² (gsm) |
Auto Document Feeder |
50 - 105 g/m² (gsm) |
Standard Interfaces | |
Wired | USB 2.0 High Speed, 10Base-T/100Base-TX |
Wireless | Wi-Fi 802.11b/g/n (Infrastructure Mode, WPS, Direct Connection) |
Network Protocol | |
LPD, RAW, WSD-Print (IPv4, IPv6) | |
TCP/IP Application Services | Bonjour(mDNS), DHCP, BOOTP, RARP, Auto IP (IPv4), DHCPv6 (IPv6) |
Management | SNMP v1/v3 (IPv4, IPv6), HTTP/HTTPS, SNTP |
Network Security | |
Wired | IP/Mac Address Filtering, HTTPS, SNMPv3, IEEE802.1X, TLS 1.3 |
Wireless | Infrastructure Mode: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA-EAP (AES), WPA2-EAP (AES) Access Point Mode: WPA2-PSK (AES) |
Mobile Solution | Canon PRINT Business, Canon Print Service, Apple® AirPrint®, Mopria® Print Service, Microsoft Universal Print |
Compatible Operating Systems*4 | Windows®, Windows Server®, Mac® OS, Linux, Chrome OS |
Software Included | Printer Driver, Fax Driver, Scanner Driver, MF Scan Utility, Toner Status |
Device Memory | 256 MB |
Display | 9.3cm (6-Line) LCD Touchscreen |
Power Requirements | AC 220 - 240 V, 50/60 Hz |
Power Consumption (Approx.) | |
Operation | 530 W (maximum 1,300 W) |
Standby | 5.8 W |
Sleep | 1.0 W |
Operating Environment | |
Temperature | 10 - 30°C |
Humidity | 20 - 80% RH (no condensation) |
Monthly Duty Cycle*5 | 20,000 prints |
Dimensions (W x D x H) (Approx.) | 390 x 374 x 368 mm |
Weight*6 (Approx.) | 11 kg |
Toner Cartridge*7 | |
Standard | Cartridge 071: 1,200 prints (Bundled: 700 pages) |
High | Cartridge 071H : 2,500 prints |
Printing Method | Monochrome Laser Beam Printing |
Print Speed *1 | |
A4 | 29 pages/minute |
Letter | 30 pages/minute |
2-Sided | 18 pages/minute (A4) / 19 pages/minute (Letter) |
Print Resolution | 600 x 600 dpi |
Print Quality with Image Refinement Technology | 2,400 (equivalent) x 600 dpi |
Warm-Up Time (From Power On) | 7.5s |
First Print Out Time (FPOT) *1 (Approx.) | |
A4 | 5.4s |
Recovery Time (From Sleep Mode) | 3.2s |
Print Language | UFR II |
Auto Duplex Print | Yes |
Print Margins | Top/Bottom/Left/Right margin: 5 mm Top/Bottom/Left/Right margin: 10 mm (Envelope) |
Copy Speed *1 | |
A4 | 29 pages/minute |
Copy Resolution | 600 × 600 dpi |
First Copy Out Time (FCOT) (Approx.) Platen Glass |
|
A4 | 7.6s |
First Copy Out Time (FCOT) (Approx.) ADF |
|
A4 | 8.9s |
Maximum Number of Copies | Up to 999 copies |
Reduce/Enlargement | 25 - 400% in 1% increments |
Copy Features | Collate, 2 on 1, 4 on 1, ID Card Copy, Passport Copy |
Scan Resolution | |
Optical | Up to 600 x 600 dpi |
Driver Enhanced | Up to 9,600 x 9,600 dpi |
Scan Type | Colour Contact Image Sensor |
Maximum Scan Size | |
Platen Glass | Up to 216 x 297 mm |
Auto Document Feeder | Up to 216 x 356 mm |
Scan Speed *2 | |
Platen Glass | 3.5s or less |
Auto Document Feeder | 20 images/minute (ipm) (mono), 15 images/minute (ipm) (colour) |
Colour Depth | 24-bit |
Pull Scan | Yes, USB and Network |
Push Scan (Scan To PC) with MF Scan Utility | Yes, USB and Network |
Scan To Cloud | MF Scan Utility |
Scan Driver Compatibility | TWAIN, WIA |
Modem Speed |
Up to 33.6 Kbps (Up to 3s/page) |
Fax Resolution |
Up to 200 x 400 dpi |
Compression Method |
MH, MR, MMR, JBIG |
Memory Capacity *3 |
Up to 256 pages |
Speed Dials |
Up to 104 dials |
Group Dials / Destinations |
Maximum 103 dials / Maximum 50 destinations in one group |
Sequential Broadcast |
Maximum 114 destinations |
Receive Mode |
Fax only, Fax/Tel Auto Switch, Answer Mode, Manual |
Memory Backup |
Permanent fax memory backup |
Fax Features |
Fax Forwarding, Remote Reception, PC Fax (Transmit only) DRPD, ECM, Auto Redial, Fax Activity Reports, Fax Activity Result Reports, Fax Activity Management Reports |
Input Tray Capacity (Plain Paper, 80 g/m² (gsm)) |
|
Standard | |
Paper Tray | 150 sheets |
Auto Document Feeder | 35 sheets |
Output Tray Capacity (Plain Paper, 80 g/m² (gsm)) |
100 sheets |
Media Size | |
Paper Tray |
A4, A5, A6, B5, Legal, Letter, Executive, Statement, Foolscap, Government Letter, Government Legal, Indian Legal, Index Card, Postcard, Envelope (COM10, Monarch, DL, C5), |
Auto Document Feeder |
A4, B5, A5, B6, Letter, Legal |
2-Sided Printing |
A4, Legal, Letter, Foolscap, Indian Legal, |
Media Type | Plain Paper, Recycled Paper, Label, Postcard, Envelope |
Media Weight | |
Paper Tray |
60 - 163 g/m² (gsm) |
Auto Document Feeder |
50 - 105 g/m² (gsm) |
Standard Interfaces | |
Wired | USB 2.0 High Speed, 10Base-T/100Base-TX |
Network Protocol | |
LPD, RAW, WSD-Print (IPv4, IPv6) | |
TCP/IP Application Services | Bonjour(mDNS), DHCP, BOOTP, RARP, Auto IP (IPv4), DHCPv6 (IPv6) |
Management | SNMP v1/v3 (IPv4, IPv6), HTTP/HTTPS, SNTP |
Network Security | |
Wired | IP/Mac Address Filtering, HTTPS, SNMPv3, IEEE802.1X, TLS 1.3 |
Mobile Solution | Canon PRINT Business, Canon Print Service, Apple® AirPrint®, Mopria® Print Service, Microsoft Universal Print |
Compatible Operating Systems*4 | Windows®, Windows Server®, Mac® OS, Linux, Chrome OS |
Software Included | Printer Driver, Fax Driver, Scanner Driver, MF Scan Utility, Toner Status |
Printing Method |
Monochrome Laser Beam Printing |
Print Speed *1 |
|
A4 |
29 pages/minute |
Letter |
30 pages/minute |
2-Sided |
18 pages/minute (A4) / 19 pages/minute (Letter) |
Print Resolution |
600 x 600 dpi |
Print Quality with Image Refinement Technology |
2 400 (equivalent) x 600 dpi |
Warm-Up Time (From Power On) |
7.5s |
First Print Out Time (FPOT) *1 (Approx.) |
|
A4 |
5.4s |
Recovery Time (From Sleep Mode) |
3.2s or less |
Print Language |
UFR II |
Auto Duplex Print |
Yes |
Print Margins |
Top/Bottom/Left/Right margin: 5 mm |
Input Tray Capacity (Plain Paper, 80 g/m² (gsm)) |
|
Standard |
|
Paper Tray |
150 sheets |
Output Tray Capacity (Plain Paper, 80 g/m² (gsm)) |
100 sheets |
Media Size |
|
Paper Tray |
A4, A5, A6, B5, Legal, Letter, Executive, Statement, Foolscap, Government Letter, Government Legal, Indian Legal, Index Card, Postcard, Envelope (COM10, Monarch, DL, C5), |
2-Sided Printing |
A4, Legal, Letter, Foolscap, Indian Legal |
Media Type |
Plain Paper, Recycled Paper, Label, Postcard, Envelope |
Media Weight |
|
Paper Tray |
60 - 163 g/m² (gsm) |
2-Sided Printing |
60 - 105 g/m² (gsm) |
Standard Interfaces |
|
Wired |
USB 2.0 High Speed, 10Base-T/100Base-TX |
Wireless |
Wi-Fi 802.11b/g/n |
Network Protocol |
|
|
LPD, RAW, WSD-Print (IPv4, IPv6) |
Network Security |
|
Wired |
IP/Mac Address Filtering, HTTPS, SNMPv3, IEEE802.1X, TLS 1.3 |
Wireless |
Infrastructure Mode: WEP (64/128 bit), |
Mobile Solution |
Canon PRINT Business, Canon Print Service, Apple® AirPrint®, Mopria® Print Service, Microsoft Universal Print |
Compatible Operating Systems*2 |
Windows®, Windows Server®, Mac® OS, Linux, Chrome OS |
Software Included |
Printer Driver, Toner Status |
Device Memory |
256 MB |
Display |
5.3cm (5-Line) LCD |
Power Requirements |
AC 220 - 240 V, 50/60 Hz |
Power Consumption (Approx.) |
|
Operation |
530 W (maximum 1 300 W) |
Standby |
3.5 W |
Sleep |
1.0 W |
Operating Environment |
|
Temperature |
10 - 30°C |
Humidity |
20 - 80% RH (no condensation) |
Monthly Duty Cycle*3 |
20 000 pages |
Dimensions (W x D x H) (Approx.) |
356 x 283 x 213 mm |
Weight*4 (Approx.) |
5.6 kg |
Toner Cartridge*5 |
|
Standard |
Cartridge 071: 1 200 prints (Bundled: 700 pages) |
High |
Cartridge 071H : 2 500 prints |
Printing Method |
Monochrome Laser Beam Printing |
Print Speed |
|
A4 |
61 pages per minute (ppm) |
Letter |
65 pages per minute (ppm) |
2-Sided |
50 images per minute (ipm) (A4) / 53 images per minute (ipm) (Letter) |
Print Resolution |
600 x 600 dpi |
Print Quality with Image Refinement Technology |
1 200 x 1 200 dpi (Equivalent) |
Warm-Up Time (From Power On) |
22s |
First Print Out Time (FPOT) (Approx.) |
|
A4 |
4.9s |
Letter |
4.9s |
Recovery Time (From Sleep Mode) |
2.0s or less |
Print Language |
UFR II, PCL 6, Adobe® PostScript® 3™ |
Auto Duplex Print |
Yes |
Print Margins |
Top/Bottom/Left/Right margin: 5 mm |
Supported File Format for USB Direct Print |
JPEG, TIFF, PDF, XPS |
Input Tray Capacity (Plain Paper, 80 g/m2) |
|
Standard |
|
Cassette |
550 sheets |
Multi-Purpose Tray |
100 sheets |
Optional |
|
Paper Feeder |
550 sheets (x3) |
Paper Deck |
2 000 sheets (x1) |
Maximum |
4 300 sheets (Standard + 3 Paper Feeders + 1 Paper Deck) |
Output Tray Capacity (Plain Paper, 80 g/m2) |
500 sheets |
Media Size |
|
Cassette / Paper Feeder |
A4, A5, A6, B5, B6, Legal, Letter, Executive, Statement, Foolscap, Government Letter, Government Legal, Indian Legal |
Multi-Purpose Tray |
A4, A5, A6, B5, B6, Legal, Letter, Executive, Statement, Foolscap, Government Letter, Government Legal, Indian Legal, Index Card, Envelope (COM10, Monarch, DL, C5) |
Paper Deck |
A4, Legal, Letter |
2-Sided Printing |
A4, A5, B5, Legal, Letter, Executive, Foolscap, Government Letter, Government Legal, Indian Legal |
Media Type |
Plain Paper, Recycled Paper, Colour Paper, Label, Postcard, Envelope |
Media Weight |
|
Standard Cassette / Paper Feeder / Paper Deck |
60 - 135 g/m2 |
Multi-Purpose Tray |
60 - 199 g/m2 |
2-Sided Printing |
60 - 120 g/m2 |
Standard Interfaces |
|
Wired |
USB 2.0 High Speed, 10Base-T/100Base-TX/1000Base-T |
Wireless |
Wi-Fi 802.11b/g/n |
Network Protocol |
|
|
TCP/IP |
TCP/IP Application Services |
Bonjour (mDNS), HTTP, HTTPS, POP before SMTP (IPv4, IPv6), DHCP, Auto IP, WINS (IPv4), DHCPv6 (IPv6) |
Management |
SNMPv1, SNMPv3 (IPv4, IPv6) |
Network Security |
|
Wired |
IP/Mac address filtering, SSL (HTTPS, IPPS), SNMPv3, IEEE802.1X, IPsec, TLS 1.3, Dual Network Support |
Wireless |
Infrastructure Mode: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA3-SAE (AES), WPA-EAP (AES), WPA2-EAP (AES), WPA3-EAP (AES), IEEE802.1X |
Other Features |
Department ID, Forced Hold Printing, Secure Print |
Mobile Solution |
Canon PRINT Business, Canon Print Service, Apple® AirPrint®, Mopria® Print Service, Microsoft Universal Print |
Compatible Operating Systems*1 |
Windows®, Windows Server®, Mac® OS, Linux |
Software Included |
Printer Driver, Toner Status |
Device Memory |
2 GB |
Display |
6.9cm (5-Line) LCD with Vari-Angle |
Power Requirements |
AC 220 - 240 V, 50/60 Hz |
Power Consumption (Approx.) |
|
Operation |
772 W (Max. 1 500 W) |
Standby |
13.7 W |
Sleep |
1.0 W |
Operating Environment |
|
Temperature |
10 - 30°C |
Humidity |
20% - 80% RH (no condensation) |
Monthly Duty Cycle*2 |
275,000 pages |
Dimensions (W x D x H) (Approx.) |
430 x 465 x 370 mm |
Weight*3 (Approx.) |
20 kg |
Toner Cartridge*4 |
|
Standard |
Cartridge 073: 27 000 prints (bundled: 11,500 prints) |
Printing Method | Colour Laser Beam Printing |
Print Speed | |
A4 | 33 / 33 pages per minute (ppm) (Mono / Colour) |
Letter | 35 / 35 pages per minute (ppm) (Mono / Colour) |
2-sided | 29 / 29 pages per minute (ppm) (Mono / Colour) |
Print Resolution | 600 x 600 dpi |
Print Quality with Image Refinement Technology | 1 200 (eq.) x 1 200 dpi (eq.) |
Warm-Up Time (From Power On) | 19.4s or less |
First Print Out Time (FPOT) | |
A4 | Approx. 7.1 / 7.1s (Mono / Colour) |
Letter | Approx 7.0 / 7.0s (Mono / Colour) |
Recovery Time (From Sleep Mode) | 1.7s or less |
Print Language | UFR II, PCL 6, Adobe® PostScript® 3™ |
Auto Duplex Print | Yes |
Print Margins | Top/Bottom/Left/Right Margin: 5 mm Top/Bottom/Left/Right Margin: 10 mm (Envelope) |
Supported File Format for USB Direct Print | JPEG, TIFF, PDF |
Paper Input (Based on 80 g/m²) | |
Standard Cassette | 250 sheets |
Multi-Purpose Tray | 50 sheets |
Optional Paper Feeder | 550 sheets |
Maximum Paper Input Capacity | 850 sheets |
Paper Output | 150 sheets |
Paper Sizes | |
Standard Cassette | A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Envelope (COM10, Monarch, C5, DL) Custom (min. 98.0 x 148.0 mm to max. 216.0 x 356.0 mm) |
Multi-Purpose Tray | A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Index Card, Envelope (COM10, Monarch, C5, DL) Custom (min. 76.0 x 127.0 mm to max. 216.0 x 356.0 mm) |
Optional Paper Feeder | A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal Custom (min. 100.0 x 148.0 mm to max. 216.0 x 356.0 mm) |
Available Paper Size for Auto Duplex Print | A4, B5, A5, Letter, Legal, Executive, Foolscap, Indian Legal |
Paper Types | Plain, Thick, Coated, Recycled, Colour, Label, Postcard, Envelope |
Paper Weight | |
Standard Cassette / Optional Paper Feeder |
60 to 200 g/m2 |
Multi-Purpose Tray | 60 to 200 g/m2 |
Standard Interfaces | |
Wired | USB 2.0 High Speed, 10Base-T/100Base-TX/1000Base-T |
Wireless | Wi-Fi 802.11b/g/n (Infrastructure mode, WPS, Direct Connection) |
Network Protocol | |
LPD, RAW, WSD-Print (IPv4, IPv6) | |
TCP/IP Application Services | Bonjour (mDNS), HTTP, HTTPS, POP before SMTP (IPv4, IPv6), DHCP, ARP+PING, Auto IP, WINS (IPv4), DHCPv6 (IPv6) |
Management | SNMPv1, SNMPv3 (IPv4, IPv6) |
Network Security | |
Wired | IP/Mac address filtering, HTTPS, SNMPv3, IEEE802.1x, IPSEC, TLS 1.3 |
Wireless | Infrastructure Mode: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA-EAP (AES), WPA2-EAP (AES), IEEE802.1x Access Point Mode: WPA2-PSK (AES) |
Other Features | Department ID, Secure Print, Application Library |
Mobile Solution | Canon PRINT Business, Canon Print Service, Apple® AirPrint®, Mopria® Print Service, Microsoft Universal Print |
Compatible Operating Systems | Windows®, Windows Server®, Mac® OS, Linux*1 |
Software Included | Printer driver, Toner Status |
Device Memory | 1 GB |
Display | WVGA Colour LCD 12.7cm (5.0in) Touch Screen Display |
Dimensions (W x D x H) (Approx.) | 425 x 427 x 380 mm |
Weight (Approx.) | 16.1 kg |
Power Consumption | |
Maximum (Operation) | 1,380 W or less |
Average (Operation) | 700 W |
Average (Standby) | 24.0 W |
Average (Sleep) | 1.0 W (USB/Wired/Wireless) |
Operating Environment | |
Temperature | 10 - 30°C |
Humidity | 20% - 80% RH (no condensation) |
Power Requirements | AC 220 - 240 V (+/-10%), 50/60 Hz (+/-2 Hz) |
Printing Method | Colour Laser Beam Printing |
Print Speed | |
A4 | 33 / 33 pages per minute (ppm) (Mono / Colour) |
Letter | 35 / 35 pages per minute (ppm) (Mono / Colour) |
2-Sided | 29 / 29 pages per minute (ppm) (Mono / Colour) |
Print Resolution | 600 x 600 dpi |
Print Quality with Image Refinement Technology | 1 200 (eq.) x 1 200 dpi (eq.) |
Warm-Up Time (From Power On) | 14s or less |
First Print Out Time (FPOT) (Approx.) | |
A4 | 7.1 / 7.1s (Mono / Colour) |
Letter | 7.0 / 7.0s (Mono / Colour) |
Recovery Time (From Sleep Mode) | 5.3s or less |
Print Language | UFR II, PCL 6 |
Auto Duplex Print | Yes |
Print Margins | Top/Bottom/Left/Right Margin: 5 mm Top/Bottom/Left/Right Margin: 10 mm (Envelope) |
Supported File Format for USB Direct Print | JPEG, TIFF, PDF |
Copy Speed A4 | |
A4 | 33 / 33 pages per minute (ppm) (Mono / Colour) |
Letter | 35 / 35 pages per minute (ppm) (Mono / Colour) |
Copy Resolution | 600 x 600 dpi |
First Copy Out Time (FCOT) (Approx.) | |
A4 | 7.6 / 8.8s (Mono / Colour) |
Letter | 7.4 / 8.6s (Mono / Colour) |
Maximum Number of Copies | Up to 999 copies |
Reduce/Enlargement | 25 - 400% in 1% increments |
Copy Features | Frame Erase, Collate, 2 on 1, 4 on 1, ID Card Copy, Passport Copy |
Scan Resolution | |
Optical | Platen glass: up to 600 x 600 dpi Feeder: up to 300 x 300 dpi |
Driver Enhanced | Up to 9 600 x 9 600 dpi |
Scan Type | Colour Contact Image Sensor |
Maximum Scan Size | |
Platen Glass | Up to 216.0 x 297mm |
Feeder | Up to 216.0 x 355.6mm |
Scan Speed*1 | 1-Sided: 50 images per minute (ipm) (mono), 40 images per minute (ipm) (colour) 2-Sided: 100 images per minute (ipm) (mono), 80 images per minute (ipm) (colour) |
Colour Depth | 24-bit |
Pull Scan | Yes, USB and Network |
Push Scan (Scan To PC) with MF Scan Utility | Yes, USB and Network |
Scan To USB (via USB Host 2.0) | Yes |
Scan To Cloud | MF Scan Utility |
Scan Driver Compatibility | TWAIN, WIA |
SEND Method | SMB, Email, FTP |
Colour Mode | Full Colour, Greyscale, Monochrome |
Scan Resolution | 300 x 600 dpi |
File Format | JPEG, TIFF, PDF, Compact PDF, PDF (OCR) |
Auto Document Feeder (ADF) | Duplex ADF: 50 sheets (80 g/m2) |
Available Paper Size for ADF | A4, B5, A5, A6, Letter, Legal, Statement, Business Card (min. 48.0 x 85.0 mm to max. 216.0 x 355.6 mm) |
Paper Input (Based on 80 g/m2) |
|
Standard Cassette | 250 sheets |
Multi-Purpose Tray | 50 sheets |
Optional Paper Feeder | 550 sheets |
Maximum Paper Input Capacity | 850 sheets |
Paper Output | 150 sheets |
Paper Sizes | |
Standard Cassette | A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Envelope (COM10, Monarch, C5, DL) Custom (min. 98.0 x 148.0 mm to max. 216.0 x 356.0 mm) |
Multi-Purpose Tray | A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Index Card, Envelope (COM10, Monarch, C5, DL) Custom (min. 76.0 x 127.0 mm to max. 216.0 x 356.0 mm) |
Optional Paper Feeder | A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal Custom (min. 100.0 x 148.0 mm to max. 216.0 x 356.0 mm) |
Available Paper Size for Auto Duplex Print | A4, B5, A5, Letter, Legal, Executive, Foolscap, Indian Legal |
Paper Types | Plain, Thick, Coated, Recycled, Colour, Label, Postcard, Envelope |
Paper Weight | |
ADF | 50 to 105 g/m2 |
Standard Cassette / Optional Paper Feeder |
60 to 200 g/m2 |
Multi-Purpose Tray | 60 to 200 g/m2 |
Standard Interfaces | |
Wired | USB 2.0 High Speed, 10Base-T/100Base-TX/1000Base-T |
Wireless | Wi-Fi 802.11b/g/n (Infrastructure mode, WPS, Direct Connection) |
Network Protocol | |
LPD, RAW, WSD-Print (IPv4, IPv6) | |
Scan | Email, SMB, WSD-Scan (IPv4, IPv6), FTP |
TCP/IP Application Services | Bonjour (mDNS), HTTP, HTTPS, POP before SMTP (IPv4, IPv6), DHCP, ARP+PING, Auto IP, WINS (IPv4), DHCPv6 (IPv6) |
Management | SNMPv1, SNMPv3 (IPv4,IPv6) |
Network Security | |
Wired | IP/Mac address filtering, HTTPS, SNMPv3, IEEE802.1x, IPSEC, TLS 1.3 |
Wireless | Infrastructure Mode: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA-EAP (AES), WPA2-EAP (AES), IEEE802.1x Access Point Mode: WPA2-PSK (AES) |
Other Features | Department ID, Secure Print, Application Library |
Mobile Solution | Canon PRINT Business, Canon Print Service, Apple® AirPrint®, Mopria® Print Service, Microsoft Universal Print |
Address Book | LDAP |
Compatible Operating Systems*3 | Windows®, Windows Server®, Mac® OS, Linux*4 |
Software Included | Printer driver, Scanner driver, MF Scan Utility, Toner Status |
Device Memory | 1 GB |
Display | WVGA Colour LCD 5-inch Touch Screen Display |
Dimensions (W x D x H) (Approx.) | 425 x 461 x 430 mm |
Weight (Approx.) | 21.7 kg |
Printing Method | Colour Laser Beam Printing |
Print Speed | |
A4 | 33 / 33 pages per minute (ppm) (Mono / Colour) |
Letter | 35 / 35 pages per minute (ppm) (Mono / Colour) |
2-sided | 29 / 29 pages per minute (ppm) (Mono / Colour) |
Print Resolution | 600 x 600 dpi |
Print Quality with Image Refinement Technology | 1 200 (eq.) x 1 200 dpi (eq.) |
Warm-Up Time (From Power On) | 19.4s or less |
First Print Out Time (FPOT) | |
A4 | Approx. 7.1 / 7.1s (Mono / Colour) |
Letter | Approx 7.0 / 7.0s (Mono / Colour) |
Recovery Time (From Sleep Mode) | 1.7s or less |
Print Language | UFR II, PCL 6, Adobe® PostScript® 3™ |
Auto Duplex Print | Yes |
Print Margins | Top/Bottom/Left/Right Margin: 5 mm Top/Bottom/Left/Right Margin: 10 mm (Envelope) |
Supported File Format for USB Direct Print | JPEG, TIFF, PDF |
Paper Input (Based on 80 g/m²) | |
Standard Cassette | 250 sheets |
Multi-Purpose Tray | 50 sheets |
Optional Paper Feeder | 550 sheets |
Maximum Paper Input Capacity | 850 sheets |
Paper Output | 150 sheets |
Paper Sizes | |
Standard Cassette | A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Envelope (COM10, Monarch, C5, DL) Custom (min. 98.0 x 148.0 mm to max. 216.0 x 356.0 mm) |
Multi-Purpose Tray | A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Index Card, Envelope (COM10, Monarch, C5, DL) Custom (min. 76.0 x 127.0 mm to max. 216.0 x 356.0 mm) |
Optional Paper Feeder | A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal Custom (min. 100.0 x 148.0 mm to max. 216.0 x 356.0 mm) |
Available Paper Size for Auto Duplex Print | A4, B5, A5, Letter, Legal, Executive, Foolscap, Indian Legal |
Paper Types | Plain, Thick, Coated, Recycled, Colour, Label, Postcard, Envelope |
Paper Weight | |
Standard Cassette / Optional Paper Feeder |
60 to 200 g/m2 |
Multi-Purpose Tray | 60 to 200 g/m2 |
Standard Interfaces | |
Wired | USB 2.0 High Speed, 10Base-T/100Base-TX/1000Base-T |
Wireless | Wi-Fi 802.11b/g/n (Infrastructure mode, WPS, Direct Connection) |
Network Protocol | |
LPD, RAW, WSD-Print (IPv4, IPv6) | |
TCP/IP Application Services | Bonjour (mDNS), HTTP, HTTPS, POP before SMTP (IPv4, IPv6), DHCP, ARP+PING, Auto IP, WINS (IPv4), DHCPv6 (IPv6) |
Management | SNMPv1, SNMPv3 (IPv4, IPv6) |
Network Security | |
Wired | IP/Mac address filtering, HTTPS, SNMPv3, IEEE802.1x, IPSEC, TLS 1.3 |
Wireless | Infrastructure Mode: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA-EAP (AES), WPA2-EAP (AES), IEEE802.1x Access Point Mode: WPA2-PSK (AES) |
Other Features | Department ID, Secure Print |
Mobile Solution | Canon PRINT Business, Canon Print Service, Apple® AirPrint®, Mopria® Print Service, Microsoft Universal Print |
Compatible Operating Systems | Windows®, Windows Server®, Mac® OS, Linux*1 |
Software Included | Printer driver, Toner Status |
Device Memory | 1 GB |
Display | 6.9cm (5-line) LCD |
Dimensions (W x D x H) (approx.) | 425 x 427 x 300 mm |
Weight (approx.) | 15.5kg |
Power Consumption | |
Maximum (Operation) | 1 380 W or less |
Average (Operation) | 700 W |
Average (Standby) | 24.0 W |
Average (Sleep) | 1.0 W (USB/Wired/Wireless) |
Operating Environment | |
Temperature | 10 - 30°C |
Humidity | 20% - 80% RH (no condensation) |
Power Requirements | AC 220 - 240 V (+/-10%), 50/60 Hz (+/-2 Hz) |
Printing Method |
Colour Laser Beam Printing |
Print Speed |
|
A4 |
33 / 33 pages per minute (ppm) (mono / colour) |
Letter |
35 / 35 pages per minute (ppm) (mono / colour) |
2-Sided |
29 / 29 pages per minute (ppm) (mono / colour) |
Print Resolution |
600 x 600 dpi |
Print Quality with Image Refinement Technology |
1 200 (eq.) x 1 200 dpi (eq.) |
Warm-Up Time (From Power On) |
14s or less |
First Print Out Time (FPOT) (Approx.) |
|
A4 |
7.1 / 7.1s (mono / colour) |
Letter |
7.0 / 7.0s (mono / colour) |
Recovery Time (From Sleep Mode) |
5.3s or less |
Print Language |
UFR II, PCL 6, Adobe® PostScript® 3™ |
Auto Duplex Print |
Yes |
Print Margins |
Top/Bottom/Left/Right Margin: 5 mm |
Supported File Format for USB Direct Print |
JPEG, TIFF, PDF |
Copy Speed A4 |
|
A4 |
33 / 33 pages per minute (ppm) (mono / colour) |
Letter |
35 / 35 pages per minute (ppm) (mono / colour) |
Copy Resolution |
600 x 600 dpi |
First Copy Time (FCOT) (Approx.) |
|
A4 |
7.6 / 8.8s (Mono / Colour) |
Letter |
7.4 / 8.6s (Mono / Colour) |
Maximum Number of Copies |
Up to 999 copies |
Reduce/Enlargement |
25 - 400% in 1% increments |
Copy Features |
Frame Erase, Collate, 2 on 1, 4 on 1, ID Card Copy, Passport Copy |
Scan Resolution |
|
Optical |
Platen glass: up to 600 x 600 dpi |
Driver Enhanced |
Up to 9 600 x 9 600 dpi |
Scan Type |
Colour Contact Image Sensor |
Maximum Scan Size |
|
Platen glass |
Up to 216.0 x 297mm |
Feeder |
Up to 216.0 x 355.6mm |
Scan Speed *1 |
1-Sided: 50 images per minute (ipm) (mono), 40 images per minute (ipm) (colour) |
Colour Depth |
24-bit |
Pull Scan |
Yes, USB and Network |
Push Scan (Scan To PC) with MF Scan Utility |
Yes, USB and Network |
Scan To USB (via USB Host 2.0) |
Yes |
Scan To Cloud |
MF Scan Utility |
Scan Driver Compatibility |
TWAIN, WIA |
SEND Method |
SMB, Email, FTP, iFAX |
Colour Mode |
Full Colour, Grayscale, Monochrome |
Scan Resolution |
300 x 600 dpi |
File Format |
JPEG, TIFF, PDF, Compact PDF, PDF (OCR) |
Modem Speed |
Up to 33.6 Kbps |
Fax Resolution |
Up to 408 x 392 dpi |
Compression Method |
MH, MR, MMR, JBIG |
Memory Capacity*2 |
Up to 512 pages |
Favourite Dials (In address book) |
19 dials |
Speed Dial (Coded dials) |
Up to 281 dials |
Group Dials / Destinations |
Max. 299 dials / Max. 299 destinations |
Duplex Fax (Transmission) |
Yes |
Sequential Broadcast |
Max. 310 destinations |
Receive Mode |
Fax Only, Manual, Answering, Fax/Tel Auto Switch |
Memory Backup |
Permanent fax memory backup (backup with flash memory) |
Fax Features |
Fax Forwarding, Dual Access, Remote Reception, PC Fax (Transmission only), DRPD, ECM, Auto Redial, Fax Activity Reports, Fax Activity Result Reports, Fax Activity Management Reports |
Transmission Time |
Approx. 2.6s |
Auto Document Feeder (ADF) |
Duplex ADF: 50 sheets (80 g/m2) |
Available Paper Size for ADF |
A4, B5, A5, A6, Letter, Legal, Statement, Business Card |
Paper Input (Based on 80 g/m2) |
|
Standard Cassette |
250 sheets |
Multi-Purpose Tray |
50 sheets |
Optional Paper Feeder |
550 sheets |
Maximum Paper Input Capacity |
850 sheets |
Paper Output |
150 sheets |
Paper Sizes |
|
Standard Cassette |
A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Envelope (COM10, Monarch, C5, DL) |
Multi-Purpose Tray |
A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Index Card, Envelope (COM10, Monarch, C5, DL) |
Optional Paper Feeder |
A4, B5, A5, A6, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal |
Available Paper Size for Auto Duplex Print |
A4, B5, A5, Letter, Legal, Executive, Foolscap, Indian Legal |
Paper Types |
Plain, Thick, Coated, Recycled, Colour, Label, Postcard, Envelope |
Paper Weight |
|
ADF |
50 to 105 g/m2 |
Standard Cassette / Optional Paper Feeder |
60 to 200 g/m2 |
Multi-Purpose Tray |
60 to 200 g/m2 |
Standard Interfaces |
|
Wired |
USB 2.0 High Speed, 10Base-T/100Base-TX/1000Base-T |
Wireless |
Wi-Fi 802.11b/g/n |
Network Protocol |
|
|
LPD, RAW, WSD-Print (IPv4, IPv6) |
Scan |
Email, SMB, WSD-Scan(IPv4, IPv6), FTP |
TCP/IP Application Services |
Bonjour (mDNS), HTTP, HTTPS, POP before SMTP (IPv4, IPv6), DHCP, ARP+PING, Auto IP, WINS (IPv4), DHCPv6 (IPv6) |
Management |
SNMPv1, SNMPv3 (IPv4, IPv6) |
Network Security |
|
Wired |
IP/Mac address filtering, HTTPS, SNMPv3, IEEE802.1x, IPSEC, TLS 1.3 |
Wireless |
Infrastructure Mode: WEP (64/128 bit), WPA-PSK (TKIP/AES), WPA2-PSK (TKIP/AES), WPA-EAP (AES), WPA2-EAP (AES), IEEE802.1x |
Other Features |
Department ID, Secure Print, Application Library |
Mobile Solution |
Canon PRINT Business, Canon Print Service, Apple® AirPrint®, Mopria® Print Service, Microsoft Universal Print |
Address Book |
LDAP |
Compatible Operating Systems*3 |
Windows®, Windows Server®, Mac® OS, Linux*4 |
Software Included |
Printer driver, Fax driver, Scanner driver, MF Scan Utility, Toner Status |
Device Memory |
1 GB |
Display |
WVGA Colour LCD 5-inch Touch Screen Display |
Dimensions (W x D x H) (approx.) |
425 x 461 x 430 mm |
Weight (approx.) |
22.0 kg |
Power Consumption (approx.) |
|
Maximum (Operation) |
1 380 W or less |
Average (Operation) |
700 W |
Average (Standby) |
24.0 W |
Average (Sleep) |
1.0 W (USB/Wired/Wireless) |
Operating Environment |
|
Temperature |
10 - 30°C |
Humidity |
20% - 80% RH (No condensation) |
Power Requirements |
AC 220 - 240 V (+/-10%), 50/60 Hz (+/-2 Hz) |
|
|
|
Printing Method | Colour Laser Beam Printing |
Print Speed | |
A4 | 21ppm / 21ppm (Mono/Colour) |
Letter | 22ppm / 22ppm (Mono/Colour) |
2-Sided | 12ppm / 12ppm (Mono / Colour) |
Print Resolution | 600 x 600dpi |
Print Quality with Image Refinement Technology | 1 200 × 1 200 dpi (equivalent) |
Warm up Time (From Power On) | 13s |
First Print Out Time (FPOT) | |
A4 | 10.4s / 10.5s (Mono / Colour) |
Letter | 10.3s / 10.3s (Mono / Colour) |
Recovery Time (From Sleep Mode) | 6.1s |
Print Language | UFR II, PCL 6, Adobe® PostScript® 3™ |
Auto Duplex Print | Standard |
Available Paper Size for Auto Duplex Print | A4, B5, Letter, Legal, Executive, Foolscap, Indian Legal |
Print Margins | 5mm - top, bottom, left and right (Envelope: 10mm) |
Print Features | Poster, Booklet, Watermark, Page Composer, Toner Saver |
Supported File Format for USB Direct Print | Supported File Format: JPEG, TIFF, PDF |
Copy Speed A4 | |
A4 | 21ppm / 21ppm (Mono / Colour) |
Letter | 22ppm / 22ppm (Mono / Colour) |
Copy Resolution | 600 x 600dpi |
First Copy Out Time (FCOT) | |
A4 | 11.4s / 13.4s (Mono / Colour) |
Letter | 11.2s / 13.1s (Mono / Colour) |
Maximum Number of Copies | 999 copies |
Reduce/Enlargement | 25 - 400% in 1% increments |
Copy Features | Frame Erase, Collate, 2 on 1, 4 on 1, ID Card Copy, Passport Copy |
Scan Resolution | |
Optical | Platen glass: 600 x 600dpi Feeder: 300 x 300dpi |
Driver Enhanced | 9 600 x 9 600 dpi |
Scan Type | Colour Contact Image Sensor |
Maximum Scan Size | |
Platen Glass | 216.0 x 297mm |
Feeder | 216.0 x 355.6mm |
Scan Speed*1 | 1-Sided: 26.1 ipm (mono), 13.3 ipm (colour) 2-Sided: 51.2 ipm (mono), 26.1 ipm (colour) |
Colour Depth | 24bit |
Pull Scan | Yes, USB and Network |
Push Scan (Scan To PC) with MF Scan Utility | Yes, USB and Network |
Scan To USB (via USB Host 2.0) | Yes |
Scan To Cloud | MF Scan Utility |
Scan Driver Compatibility | TWAIN, WIA |
SEND Method | SMB, Email, FTP, iFAX Simple |
Colour Mode | Full Color, Grayscale, Monochrome |
Scan Resolution | 300 x 600dpi |
File Format | JPEG, TIFF, PDF, Compact PDF, PDF (OCR) |
Modem Speed | 33.6Kbps |
Fax Resolution | 408 x 392dpi |
Compression Method | MH, MR, MMR, JBIG |
Memory Capacity*2 | 512 pages |
Favourite Dials (in address book) | 19 dials |
Speed Dial (Coded dials) | 281 dials |
Group dials / Destinations | Maximum 299 dials / Maximum 299 destinations |
Duplex Fax (Transmission) | Yes |
Sequential Broadcast | Maximum 310 destinations |
Receive Mode | Fax Only, Manual, Answering, Fax/Tel Auto Switch |
Memory Backup | Permanent fax memory backup (Backup with flash memory) |
Fax Features | Fax Forwarding, Dual Access, Remote Reception, PC Fax (Transmission only), DRPD, ECM, Auto Redial, Fax Activity Reports, Fax Activity Result Reports, Fax Activity Management Reports |
Transmission Time | 2.6s |
Auto Document Feeder (ADF) | DADF: 50 sheets (80g/m2) |
Available Paper Size for DADF | A4, B5, A5, Letter, Legal, Statement (Minimum 128 x 139.7mm to Maximum 216.0 x 355.6mm) |
Paper Input (based on 80g/m2) |
|
Standard Cassette | 250 sheets |
Multi-Purpose Tray | 1 sheet |
Optional Paper Feeder | N/A |
Maximum Paper Input Capacity | 251 sheets |
Paper Output | 100 sheets |
Paper Sizes | |
Cassette | A4, B5, A5, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal Custom (Minimum 76.2 x 127.0mm to Maximum 216.0 x 355.6mm) |
Multi-Purpose Tray | A4, B5, A5, Letter, Legal, Statement, Executive, Government Letter, Government Legal, Foolscap, Indian Legal, Index Card Envelope: COM10, Monarch, C5, DL Custom (Minimum 76.2 x 127.0mm to Maximum 216.0 x 355.6mm) |
Optional Paper Feeder | N/A |
Paper Types | Plain, Thick, Coated, Recycled, Colour, Label, Postcard, Envelope |
Paper Weight | |
ADF | 50 to 105g/m2 |
Cassette / Optional Paper Feeder |
60 to 200g/m2 |
Multi-Purpose Tray | 60 to 200g/m2 |
Standard Interfaces | |
Wired | USB 2.0 High Speed, 10Base-T/100Base-TX/1000Base-T |
Wireless | Wi-Fi 802.11b/g/n (Infrastructure mode, WPS easy Setup, Direct Connection) |
Near Field Communication (NFC) | N/A |
Network Protocol | |
LPD, RAW, WSD-Print (IPv4,IPv6) | |
Scan | Email, SMB, WSD-Scan(IPv4, IPv6), FTP |
TCP/IP Application Services | Bonjour(mDNS), HTTP, HTTPS, POP before SMTP (IPv4,IPv6), DHCP, ARP+PING, Auto IP, WINS (IPv4), DHCPv6 (IPv6) |
Management | SNMPv1, SNMPv3 (IPv4,IPv6) |
Network Security | |
Wired | IP/Mac address filtering, HTTPS, SNMPv3, IEEE802.1x, IPSecurity |
Wireless | WEP 64/128 bit, WPA-PSK (TKIP/AES), WPA2-PSK (AES) |
One-Push Wireless Configuration | Wi-Fi Protected Setup (WPS) |
Other Features | Department ID, Secure Print, Application Library |
Mobile Solution | Canon PRINT Business, Canon Print Service, Google Cloud Print™, Apple® AirPrint®, Mopria® Print Service |
Address Book | LDAP |
Compatible Operating Systems*3 | Windows® 10, Windows® 8.1, Windows® 7, Windows Server® 2016, Windows Server® 2012 R2, Windows Server® 2012, Windows Server® 2008 R2, Windows Server® 2008 Mac® OS X 10.9.5 & up*4, Linux*4 |
Software Included | Printer driver, Fax driver, Scanner driver, MF Scan Utility, Toner Status |
Device Memory | 1GB |
LCD Display | WVGA Colour LCD 12.7cm(5in) Touch Screen Display |
Dimensions (W x D x H) | 451 x 460 x 413mm |
Weight | 20.5kg |
Power Consumption | |
Maximum | 850W |
Average (During Copy) | 370W |
Average (During Standby) | 11W |
Average (During Sleep) | 0.8W (USB/ LAN / Wi-Fi) |
Noise Levels*5 | |
During Operation | Sound Pressure Level: 51dB Sound Power Level: 69.4dB |
During Standby | Sound Pressure Level: Inaudible Sound Power Level: 43dB |
Operating Environment | |
Temperature | 10 - 30°C |
Humidity | 20% - 80% RH (no condensation) |
Power Requirements | AC 220-240 V (±10%), 50/60 Hz (±2Hz) |
Copy | ||
Copy Type | Monochrome Laser | |
Copy Speed | Up to 18 / 19cpm (A4 / LTR) | |
Copy Resolution | Speed priority mode: | 600 x 400dpi |
Resolution priority mode: | 600 x 600dpi | |
Halftones | 256 levels | |
Warm up Time (From Power On) | 10s or less | |
Recovery Time (From Sleep Mode) | 2s or less (Copy) 0.3s or less (Print) |
|
First Copy Time (FCOT) | 12.0 / 11.8s (A4 / LTR) | |
Paper Source | 150 sheet cassette | |
Paper Weight | 60 to 163g/m2 (cassette) | |
Papet Output | 100 sheets (face down) | |
Zoom | 50 - 200% in 10% increments | |
Copy Size | Platen: | Up to A4 / LTR |
Copy Features | 2 on 1, ID Card Copy | |
Copy Memory | 64MB (Shared) | |
Printer Type | Monochrome Laser | |
Print Speed | Up to 18 pages per minute / 19 pages per minute (A4 / LTR) | |
First Printout Time (FPOT) | 7.8s / 7.7s (A4 / LTR) | |
Print Language | UFR II LT | |
Print Resolution | Up to 600 x 600dpi, 1 200 (equivalent) x 600dpi | |
Print Memory | 64MB (Shared) | |
Scan | ||
Scan Type | CIS | |
Scan Resolution | Optical: | Up to 600 x 600dpi |
Driver enhanced: | Up to 9 600 x 9 600dpi | |
Colour Depth | 24-bit | |
Document Size | Platen: | Up to A4 |
Compatibility | TWAIN, WIA | |
Output File Format | Windows: | Hi-Compression PDF, Searchable PDF, PDF, JPEG, TIFF, BMP |
Mac: | PDF, JPEG, TIFF, BMP, PNG | |
Pull Scan | Yes, USB | |
Scan To PC | None | |
Interface / Software | ||
Standard Interface | USB 2.0 Hi-Speed | |
USB Function | Print, Scan | |
Compatible Operating Systems*1 | Windows 8 (32 / 64-bit), Windows 7 (32 / 64bit), Windows Vista (32 / 64-bit), Windows XP (32 / 64bit), Windows 2000, Mac OS X 10.4 - 10.8, Linux*3 | |
General Specifications | ||
LCD Display | 7 Segment (1 digit) LED | |
Dimensions (W x D x H) |
372 x 276 x 254mm (With the cassette closed) | |
372 x 371 x 254mm (With the cassette opened) | ||
Weight | w/CRG: | 8.2kg |
w/o CRG: | 7.6kg | |
Power Consumption | Maximum: | 960W |
During Operation: | 450W | |
Standby: | 2.5W | |
Sleep: | 1.4W | |
TEC (Typical Electricity Consumption) | 0.6kWh/W | |
Toner Cartridge*4 | Cartridge 925*2 (1 600 pages) (Bundled cartridge 700 pages) |
|
Monthly Duty Cycle | 8 000 pages | |
Recommended Monthly Print Volume | 250 - 1 000 pages |
Printing Method | Monochrome Laser Beam Printing | ||
Print Speed | A4: | 18 pages per minute | |
Letter: | 19 pages per minute | ||
Print Resolution | 600 x 600dpi | ||
Print Quality with Image Refinement Quality | 2 400 (equivalent) × 600dpi | ||
Warm-Up Time (From Power On) |
10s | ||
First Printout Time (FPOT) | 7.8s | ||
Recovery Time (From Sleep Mode) |
1s | ||
Print Language | UFR II LT | ||
Paper Handling | |||
Paper Input (Standard) | 150 sheets (based on 80g/m2) | ||
Paper Output | 100 sheets (face down) (based on 80g/m2) |
||
Paper Size | A4, B5, A5, Legal*1, Letter, Executive, 16K, Envelope COM10, Envelope Monarch, Envelope C5, Envelope DL Custom: Width 76.2 to 215.9mm x Length 188 to 355.6mm |
||
Paper Weight | 60 to 163g/m2 | ||
Paper Type | Plain paper, Heavy Paper, Transparency, Label, Envelope. | ||
Connectivity and Software | |||
USB Interface | USB 2.0 High Speed | ||
Network Interface | Wi-Fi 802.11b/g/n (WPS Easy Set Up) | ||
Network Protocol | Print: | LPD, RAW, WSD-Print | |
Management: | SNMPv1, SNMPv3, SLP TCP/IP Application Services: WINS (IPv4), DHCP, BOOTP, RARP, DHCPv6 (IPv6), Auto IP, mDNS, DNS, DDNS |
||
Network Security | WEP, WPA-PSK(TKIP/AES-CCMP), WPA2-PSK(TKIP/AES-CCMP) | ||
Mobile Print | Canon Mobile Printing | ||
Compatible Operating Systems*2 | Win 8.1 (32 / 64bit), Win 8 (32 / 64bit), Windows 7 (32 / 64-bit), Windows Vista (32 / 64-bit), Windows XP (32 / 64-bit), Windows Server 2012 (32 / 64bit), Windows Server 2012 R2 (64 bit), Windows Server 2008 (32 / 64bit), Windows Server 2008 R2 (64bit), Windows Server 2003 (32 / 64bit), Mac OS 10.6.x~10.9*3, Linux*3, Citrix |
||
General Specification | |||
Operation Panel | 3 LED indicators, 3 Operation Key | ||
Device Memory | 32MB | ||
Dimensions (W x D x H) | 364 x 249 x 199mm | ||
Weight | 5.0kg (Without Cartridge) | ||
Noise Level*4 | During Operation: | Sound Power Level: | 6.53dB |
Sound Pressure Level: | 49.3dB | ||
During Standby: | Sound Power Level: | Inaudible*5 | |
Sound Pressure Level: | Inaudible*5 | ||
Power Consumption | Maximum 840W | ||
Average Power Consumption | During Operation: | 320W | |
During Standby: | 1.8W (USB connection) 2.8W (Wireless connection) |
||
During Sleep: | 0.8 W (USB connection) 1.6W (Wireless connection) |
||
Energy Star TEC (Typical Electricity Consumption) |
0.48kWh/week | ||
Operating Environment | Temperature: | 10~30°C | |
Humidity: | 20% to 80% RH (no condensation) | ||
Power Requirement | 220 - 240V (±10%), 50 / 60Hz (±2Hz) | ||
Toner Cartridge*6 | Cartridge 925: | 1 600 pages | |
Monthly Duty Cycle*7 | 5 000 pages | ||
Recommended Monthly Print Volume | 200 - 800 pages |
Model | TASKalfa 2020 | TASKalfa 2320 | TASKalfa 2321 | ||
---|---|---|---|---|---|
Main Function | Copy, Print, Scan, Fax (Optional for TASKalfa 2321 only) | ||||
Writing Method | Semiconductor Laser | ||||
CPU | 500MHz | ||||
Print Speed (A4) | Simplex/Duplex (Optional) | 20/10 cpm | 23/11 cpm | ||
Scanning Speed (A4) 300dpi (Mono/Color) | Simplex | 23/14 ipm | |||
Duplex | 8/6 ipm | ||||
Memory | 256MB | ||||
Warm Up Time | 17.2 seconds | 18.8 seconds | |||
Paper Capacity | Stand | 400 sheets: 1 x 300 sheets (Cassette) + 100 sheets (MPT) | |||
Maximum | 1,300 sheets (Main Unit + PF-480 x 3) + MPT | ||||
Paper Size | Cassette | Max. A3 (Ledger) - Min. A5R | |||
MPT | Max. A3 (Ledger) - Min. A6R | ||||
Paper Weight | Cassette | 64 to 105 g/m2 | |||
MPT | 45 to 160 g/m2 | ||||
Duplex Printing (Optional) | Paper size: Max. A3 (Leger) - Min. A5R; Paper weight: 64 to 105 g/m2 | ||||
Display LCD (Back Light) | 2 Lines | 5 Lines | |||
128 x 32 dot | 128 x 64 dot | ||||
Dimension (W x D x H) (Main Unit) | 565 mm x 527 mm x 485 mm (with platen) | ||||
Weight (Main Unit) | 27kg (Excluding the weight of toner container) | ||||
Power Consumption (Standard configuration) | Copy/Print Mode | 378W or less | 450W or less | ||
Stand-by Mode | 74W or less | ||||
Sleep Mode | 1.1W or less | 2.3W or less | |||
Noise (ISO7779/ ISO9296) | Copy/Print Mode | 62dB(A) | |||
Stand-by Mode | 40dB(A) |
Model | TASKalfa 2020 | TASKalfa 2320 | TASKalfa 2321 | ||
---|---|---|---|---|---|
Copy Size | Max. A3 (Ledger) - Min. A6R | ||||
Resolution | 600 x 600 dpi | ||||
First Copy Time | 5.7 seconds | ||||
Zoom Ratio | 25% to 400% (1% per Step) | ||||
Multiple Copy | 1 to 999 | ||||
ID Card Copy | Yes | ||||
N-Up Copy | 2 in 1 , 4 in 1 |
Model | TASKalfa 2020 | TASKalfa 2320 | TASKalfa 2321 | ||
---|---|---|---|---|---|
Resolution | 600 x 600 dpi | ||||
First Print Time | 5.7 seconds | ||||
PDL | Host Based (GDI) | ||||
Operating System Supported | Windows: 7/8.1/10, server:2008/2008 R2/2012/2012 R2/2016; Apple Macintosh: OS X 10.9 or later; Linux | ||||
Interface | USB2.0 High Speed x1; 100BASE-TX/10BASE-T(TASKalfa 2321 only) | ||||
Network Printing | TCP/IP, NetWare, AppleTalk, NetBEUI(TASKalfa 2321 only) | ||||
Print Box | 10 | 30 |
Model | TASKalfa 2020 | TASKalfa 2320 | TASKalfa 2321 | ||
---|---|---|---|---|---|
Color Selection | Full Color; Gray scale; Mono | ||||
Resolution | Color/ Gray scale: 300dpi, 200dpi; Mono: 600dpi, 400dpi, 300dpi, 200dpi | ||||
File Format | TIFF (MMR/JPEG compression), PDF (MMR/JPEG compression/High Compression), JPEG, BMP | ||||
Image Type Mode | Text, Photo, Text + Photo | ||||
Transmission Type | Scan to PC (SMB); Scan to E-mail; TWAIN Scan; WIA Scan Scan Utility: Client Tool | ||||
TWAIN scan Address | 10 addresses | 30 addresses |
Model | TASKalfa 2020 | TASKalfa 2320 | TASKalfa 2321 | ||
---|---|---|---|---|---|
Original Size | ---- | Max. A3 (Ledger) – Min. A5 (Statement) | |||
Coding Method | ---- | MMR, MR, MH | |||
Transmission Speed | ---- | Super G3 33.6 kbps | |||
Transmission Time | ---- | 4 seconds or less (MMR) | |||
Fax Resolution | ---- | Normal, Fine, Super Fine | |||
Network FAX | ---- | Yes (Transmission only) | |||
Address Book | ---- | 100 single addresses and 20 group addresses |
|||
One Touch Dial | ---- | 32 |
Model | ECOSYS M3145dn | ECOSYS M3645dn | ECOSYS M3660idn | |
---|---|---|---|---|
Main Function | Copy, Print, Scan, Fax (ECOSYS M3645dn/M3660idn only) | |||
Writing Method | Semiconductor Laser | |||
CPU | Cortex-A9 1.2GHz | |||
Print Speed (A4) (Mono) | 45 ppm | 60 ppm | ||
Scanning Speed (A4) 300dpi (Mono/Color) | Simplex | 60/40 ipm | ||
Duplex | 26/17 ipm | 100/64 ipm | ||
Memory | Standard 1GB (Max. 3GB) | |||
Warm Up Time | 16 seconds | 25 seconds | ||
Paper Capacity | Standard | 500 sheets (Cassette) + 100 sheets (MPT) | ||
Maximum | 2,600 sheets (Main Unit + 500 sheets PF-3110 x4 + MPT) | |||
Paper Size | Cassette | Min. A5R - Max. A4 (Legal) | Min. A6R - Max. A4 (Legal) | |
Option | Min. A5R - Max. A4 (Legal) | |||
MPT | Min. 70mm x 148mm - Max. A4 (Legal) & Banner Print of 216mm x 915mm | |||
Paper Weight | Cassette | 60 - 120 g/m2 | ||
Option | 60 - 120 g/m2 | |||
MPT | 60 - 120 g/m2 | |||
Duplex Printing | Paper size: A5R to A4/Legal; Paper weight: 60 - 120 g/m2 | |||
Output Capacity | Max. 250 sheets face-down | Max. 250 sheets face-down | ||
Control Panel | 5 lines LCD | 7 inch Color Touch LCD Panel | ||
Document Processor | Standard (Max. 75 sheets RADF Type) | Standard (Max. 100 sheets One-path duplex scanning Type) | ||
Dimension (W x D x H) (Main Unit) | 475mm x 476mm x 575mm | 480mm x 495mm x 590mm | ||
Weight (Main Unit) | Approx. 22.8 kg | Approx. 24.7 kg | ||
Power Consumption (Standard configuration) | Copy/Print Mode | 652W / 630W | 746W / 723W | |
Stand-by Mode | 50W | 54W | ||
Energy Saver | 0.5W | |||
Noise (ISO7779/ ISO9296) | Copy/Print Mode | 54dB(A) | 57dB(A) | |
Stand-by Mode | 30dB(A) |
Model | ECOSYS M3145dn | ECOSYS M3645dn | ECOSYS M3660idn | |
---|---|---|---|---|
Copy Size | Max. A4 (Legal) – Min. A6R | |||
Resolution | 600 x 600 dpi | |||
First Copy Time (Mono) | 7.0 seconds or less | |||
Zoom Ratio | Manual | 25% – 400% (1% per Step) | ||
Pre-defined | 7R5E | |||
Multiple Copy | 1 – 999 |
Model | ECOSYS M3145dn | ECOSYS M3645dn | ECOSYS M3660idn |
---|---|---|---|
Resolution | 600 x 600 dpi, Fast 1200, Fine 1200 | ||
PDL | PCL6 (PCL5e, PCL-XL, PCL 5c), KPDL3 (Postscript 3 compatible), XPS | ||
First Print Out Time (Mono) | 5.9 seconds or less | 4.9 seconds or less | |
Supported Protocol | NetBEUI, FTP, Port 9100, LPR, IPP, IPP over SSL, WSD Print, Apple Bonjour | ||
Operating System Supported | Windows Server 2008, Windows Server 2008 R2, Windows Server 2012; Windows 7, Windows 10; Linux | ||
Interface | USB 2.0 High Speedx1; Ethernet 10BASE-T/100BASE-TX/1000BASE-T; USB Host Interface (USB Host)x2 | ||
USB Memory Printing | Standard | ||
USB Memory Printing Format | TIFF, JPEG, PDF, XPS |
Model | ECOSYS M3145dn | ECOSYS M3645dn | ECOSYS M3660idn |
---|---|---|---|
Color Selection | ACS; Full Color; Grayscale; Black & White | ||
Resolution | 600dpi, 400dpi, 300dpi, 200dpi, 200x400dpi, 200x100dpi | ||
File Format | TIFF, JPEG, XPS, PDF (MMR/JPG/High-compression PDF) | ||
Image Type Mode | Text, Photo, Text + Photo | ||
Transmission Type | Scan to SMB; Scan to E-mail; Scan to FTP or FTP over SSL; Scan to USB; TWAIN Scan; WSD Scan | ||
Address Storage | 200 addresses (Common address list), 50 groups (Group address list) |
Model | ECOSYS M3145dn | ECOSYS M3645dn | ECOSYS M3660idn |
---|---|---|---|
Original Size | Max. A4 (Legal) – Min. A6 | ||
Coding Method | MMR, MR, MH, JBIG | ||
Transmission Speed | 33.6 kpbs | ||
Memory | 6MB | ||
One Touch Dial | 100 numbers (ECOSYS M3645dn/M3660idn) | ||
Network FAX | Yes |
