Extraordinary Image Quality
At the heart of the Expression 12000XL is a high-definition CCD sensor with a resolution of 2400 x 4800 dpi. To eliminate image ‘ghosting’, the sensor is covered with anti-reflection coated glass while Epson’s Micro Step Drive technology moves the optical carriage with ultra-high precision to produce greater detail. Together with an optical density of 3.8 Dmax and 48-bit depth, the scanner allows you to easily and consistently achieve scans with superior tones and colour reproduction.
Impeccably Clear and Sharp Scans
Beyond optical resolution, the CCD sensor sports a new 6-line CCD sensor array with large pixels that provides greater scanning details during every pass. The scanner is also equipped with an Auto Focus system for clearer and sharper scans. The optical system can achieve pinpoint focusing automatically, or allow you to take full creative control via optional Manual Focus.
Scanner Type:A3 Flatbed colour image scannerSensor Type:6-line colour CCDLight Source:LEDOptical Resolution:2,400 x 4,800 dpiOptical Density:3.8 DmaxOutput Resolution:50 - 6,400 dpi (1 dpi increments)Scanner Bit Depth (Colour):48-bit input, 24/48-bit outputScanner Bit Depth (Grayscale):16-bit input, 8/16-bit outputScanner Bit Depth (Black & White):16-bit input, 1-bit outputMax Document Size:310 x 437mm (Reflective)
309 x 420mm (Transparancy)Film Scanning:35mm strip film x 48 Frames, 35mm mounted film x 30 Frames, (6 x 17cm) x 6 Frames, (4" x 5") x 8 Frames, up to 12.2" x 16.5"Output File Formats:JPEG, TIFF, Multi-TIFF, PDF, Searchable PDF, BMP, PNG
Flatbed (Black / Colour):300dpi: 12 sec / 12 secFilm Scanning (35mm Positive Film):1,200 dpi: 57 sec
2,400 dpi: 57 secFilm Scanning (35mm Negative Film):1,200 dpi: 61 sec
Standard:USB 2.0
