Scanner Type

Flatbed

Scanner Element

Light Source

Optical Resolution^*1

4800 x 4800dpi

Selectable Resolution^*2

25 - 19200dpi

Scanning Bit Depth

Grayscale

16-bit input
8-bit output

Colour

48-bit input (16-bit for each colour)
Win: [48 or 24-bit output (16-bit or 8-bit for each colour)]
Mac: [24-bit output (8-bit for each colour)]

*48-bit: Windows TWAIN Driver only

Scanner Speed

Preview Speed^*3

Approx. 7 s

Scan Speed^*4

Colour A4, 300dpi

Approx. 8 s

Colour 4x6, 300dpi

Approx. 4 s

Scanning Speed^*5
(Reflective)

Grayscale, B&W

8.2ms/line (4800 dpi)
4.3ms/line (2400 dpi)
2.2ms/line (1200 dpi)
1.3ms/line (600 dpi)
1.7ms/line (300 dpi)

Colour

25.4ms/line (4800 dpi)
14.8ms/line (2400 dpi)
6.6ms/line (1200 dpi)
3.8ms/line (600 dpi)
1.7ms/line (300 dpi)

Maximum Document Size

A4 / Letter (216 x 297mm)

Scanner Buttons (EZ Buttons)

5 buttons (PDF x 2, AUTOSCAN, COPY, SEND）

Interface

USB 2.0 Hi-Speed Type-C

System Requirements^*6

Windows 10 / 8.1 / 7 SP1
Mac OS 10.12 ~10.13, Mac OS X v10.11.6

Operating Environment

Temperature

5 - 35°C

Humidity

10 - 90% RH (no dew condensation)

Power Supply

Supplied via USB port

Power Consumption

Maximum during operation

approx. 4.5W

Stand-by

approx. 0.3W

Environment

Regulation

RoHS (EU, China), WEEE (EU)

Eco-label

Energy Star

Dimension (WxDxH)

250×367×42mm

Weight

1.7kg
